Union 1960s
No |
Name |
Yard No |
Builder |
Laid down |
Launched |
Comm |
Fate |
Tolland subclass |
|||||||
AKA64 |
Tolland |
130 |
North Carolina SB, Wilmington |
4.1944 |
26.6.1944 |
9.1944 |
stricken 7.1946 |
AKA65 |
Shoshone |
133 |
North Carolina SB, Wilmington |
5.1944 |
17.7.1944 |
9.1944 |
stricken 7.1946 |
AKA66 |
Southampton |
135 |
North Carolina SB, Wilmington |
5.1944 |
28.7.1944 |
9.1944 |
stricken 7.1946 |
AKA67 |
Starr |
137 |
North Carolina SB, Wilmington |
6.1944 |
18.8.1944 |
9.1944 |
stricken 6.1946 |
AKA68 |
Stokes |
139 |
North Carolina SB, Wilmington |
6.1944 |
31.8.1944 |
10.1944 |
stricken 7.1946 |
AKA69 |
Suffolk |
141 |
North Carolina SB, Wilmington |
7.1944 |
15.9.1944 |
10.1944 |
stricken 7.1946 |
AKA70 |
Tate |
143 |
North Carolina SB, Wilmington |
7.1944 |
26.9.1944 |
11.1944 |
stricken 7.1946 |
AKA71 |
Todd |
145 |
North Carolina SB, Wilmington |
8.1944 |
10.10.1944 |
11.1944 |
stricken 7.1946 |
AKA72 |
Caswell |
147 |
North Carolina SB, Wilmington |
1944 |
24.10.1944 |
12.1944 |
stricken 6.1946 |
AKA73 |
New Hannover |
148 |
North Carolina SB, Wilmington |
8.1944 |
31.10.1944 |
12.1944 |
stricken 8.1946 |
AKA74 |
Lenoir |
149 |
North Carolina SB, Wilmington |
9.1944 |
6.11.1944 |
12.1944 |
stricken 6.1946 |
AKA75 |
Alamance |
150 |
North Carolina SB, Wilmington |
9.1944 |
11.11.1944 |
12.1944 |
stricken 7.1946 |
AKA76 |
Torrance |
127 |
North Carolina SB, Wilmington |
1944 |
6.6.1944 |
6.1944 |
stricken 7.1946 |
AKA77 |
Towner |
128 |
North Carolina SB, Wilmington |
4.1944 |
18.6.1944 |
6.1944 |
stricken 6.1946 |
AKA78 |
Trego |
129 |
North Carolina SB, Wilmington |
4.1944 |
20.6.1944 |
7.1944 |
stricken 6.1946 |
AKA79 |
Trousdale |
131 |
North Carolina SB, Wilmington |
4.1944 |
3.7.1944 |
7.1944 |
stricken 5.1946 |
AKA80 |
Tyrrell |
132 |
North Carolina SB, Wilmington |
5.1944 |
30.7.1944 |
7.1944 |
stricken 5.1946 |
AKA81 |
Valencia |
134 |
North Carolina SB, Wilmington |
5.1944 |
22.7.1944 |
8.1944 |
stricken 5.1946 |
AKA82 |
Venango |
136 |
North Carolina SB, Wilmington |
6.1944 |
9.8.1944 |
8.1944 |
stricken 5.1946 |
AKA83 |
Vinton |
138 |
North Carolina SB, Wilmington |
6.1944 |
25.8.1944 |
9.1944 |
stricken 6.1946 |
AKA84 |
Waukesha |
140 |
North Carolina SB, Wilmington |
7.1944 |
6.9.1944 |
9.1944 |
stricken 7.1946 |
AKA85 |
Wheatland |
142 |
North Carolina SB, Wilmington |
7.1944 |
21.9.1944 |
10.1944 |
stricken 5.1946 |
AKA86 |
Woodford |
144 |
North Carolina SB, Wilmington |
7.1944 |
5.10.1944 |
10.1944 |
stricken 5.1946 |
AKA87 |
Duplin |
146 |
North Carolina SB, Wilmington |
1944 |
17.10.1944 |
10.1944 |
stricken 5.1946 |
AKA101 |
Ottawa |
189 |
North Carolina SB, Wilmington |
10.1944 |
29.11.1944 |
2.1945 |
stricken 3.1947 |
AKA102 |
Prentiss |
190 |
North Carolina SB, Wilmington |
10.1944 |
6.12.1944 |
2.1945 |
stricken 6.1946 |
Rankin subclass |
|||||||
AKA103, 1.1969- LKA103 |
Rankin |
193 |
North Carolina SB, Wilmington |
10.1944 |
22.12.1944 |
2.1945 |
stricken 1.1977 |
AKA104, 1.1969- LKA104 |
Seminole |
194 |
North Carolina SB, Wilmington |
1944 |
28.12.1944 |
3.1945 |
stricken 9.1976 |
AKA105, 1.1969- LKA105 |
Skagit |
187 |
North Carolina SB, Wilmington |
9.1944 |
18.11.1944 |
5.1945 |
stricken 7.1969 |
AKA106, 1.1969- LKA106 |
Union |
188 |
North Carolina SB, Wilmington |
9.1944 |
23.11.1944 |
4.1945 |
stricken 1.1976 |
AKA107, 1.1969- LKA107 |
Vermilion |
191 |
North Carolina SB, Wilmington |
10.1944 |
12.12.1944 |
6.1945 |
stricken 1.1977 |
AKA108, 1.1969- LKA108 |
Washburn |
192 |
North Carolina SB, Wilmington |
10.1944 |
18.12.1944 |
5.1945 |
stricken 10.1976 |
AKA109 |
San Joaquin |
265 |
Federal, Kearny |
--- |
--- |
--- |
cancelled 8.1945 |
AKA110 |
Sedgwick |
266 |
Federal, Kearny |
--- |
--- |
--- |
cancelled 8.1945 |
AKA111 |
Whitfield |
267 |
Federal, Kearny |
--- |
--- |
--- |
cancelled 8.1945 |
Displacement standard, t |
8635 |
Displacement full, t |
13910 |
Length, m |
132.6 wl 139.9 oa |
Breadth, m |
19.2 |
Draught, m |
7.92 max |
No of shafts |
1 |
Machinery |
1 set General Electric geared steam turbines, 2 Combustion Engineering or Foster Wheeler boilers |
Power, h. p. |
6000 |
Max speed, kts |
16.5 |
Fuel, t |
oil 1553 |
Endurance, nm(kts) |
|
Armament |
1 x 1 - 127/38 Mk 12, 4 x 2 - 40/56 Mk 1.2, 16 x 1 - 20/70 Mk 4 |
Electronic equipment |
presumably SF or SG or SH or SL or SO or SU radar |
Military load |
15 - 16 LCVP, 8 LCM(3), 1 LCP(L), 4450 t of cargo Tolland class by 1945: 6 LCM(6), 2 LCM(3), 13 LCVP, 1 LCPL, 5275 t of cargo, 62 marines |
Complement |
404 |
Project history: USN military transport vessels were sectioned into two groups: ÀÐ for transportation of troops and ÀÊ for carriage of goods and technics. The majority of them were built on the basis of standard types Ñ2, Ñ3 and Ñ4 and differed from usual cargo ships a little.
For delivery of troops and cargoes directly to a beaching place assault landing transport ships (ÀÐÀ and ÀÊÀ) served, which main difference from ÀÊ and ÀÐ consisted that they were extra equipped with disembarkation craft of LCVP, LCM and LCP (L) types; with their help delivery of people and cargoes to beach also was effected.
Originally similar ships were not outlined in own subclass and were registered as ÀÐ and ÀÊ. In February, 1943 reorganisation was done and assault transports have received indexation ÀÐÀ and ÀÊÀ.
Two ships of Doyen class, projected even on the eve of war for landing operations in Caribbean basin, became the first American assault military transports. The overwhelming majority of remaining ÀÐÀ and ÀÊÀ has been converted from merchant cargo and cargo-passenger vessels or constructed in hulls of standard cargo vessels built by the big series in days of war. An exception were specially projected as assault transports Gilliam (ÀÐÀ) and Artemis (ÀÊÀ) classes.
Besides the large landing transport ships of ÀÐÀ and ÀÊÀ classes, small landing parties and subversive groups were landed by fast landing transports (APD) converted from become outdated Wickes and Clemson classes destroyers and destroyer escorts of Buckley and Rudderow classes.
Ships of Tolland/Rankin classes were built in standard C2-S-AJ3 type hulls.
Modernizations: None
.1/1946: 1 x 1 - 127/38 Mk 30, 4 x 2 - 40/60 Mk 1, 16 x 1 - 20/70 Mk 10, SF or SG or SH or SL or SO or SU radar
Naval service: Tyrrell 2.4.1945 was damaged at Okinawa by kamikaze. Starr 9.4.1945 was damaged at Okinawa by Japanese suicide boat.
Suffolk
