Muliphen 1963
Algol 1968
No |
Name |
Yard No |
Builder |
Laid down |
Launched |
Comm |
Fate |
AKA15 |
Andromeda |
241 |
Federal, Kearny |
9.1942 |
22.12.1942 |
3.1943 |
stricken 7.1960 |
AKA16 |
Aquarius |
247 |
Federal, Kearny |
4/1943 |
23.7.1943 |
8.1943 |
stricken 11.1946 |
AKA17 |
Centaurus |
248 |
Federal, Kearny |
1943 |
3.9.1943 |
10.1943 |
stricken 9.1946 |
AKA18 |
Cepheus |
249 |
Federal, Kearny |
1943 |
23.10.1943 |
12.1943 |
stricken 9.1946 |
AKA19, 1.1969- LKA19 |
Thuban |
245 |
Federal, Kearny |
2.1943 |
26.4.1943 |
6.1943 |
stricken 1.1977 |
AKA20 |
Virgo |
246 |
Federal, Kearny |
3.1943 |
4.6.1943 |
7.1943 |
stricken 7.1961 |
AKA53, 10.1949- T-AKA53 |
Achernar |
250 |
Federal, Kearny |
9.1943 |
3.12.1943 |
1.1944 |
Military Sealift Command 10.1949, to Spain 2.1965 (Castilla) |
AKA54, 1.1969- LKA54 |
Algol (ex-James Baines) |
240 |
Moore, Oakland |
12.1942 |
17.2.1943 |
11.1943 |
stricken 1.1977 |
AKA55, 10.1949- T-AKA55 |
Alshain |
251 |
Federal, Kearny |
10.1943 |
26.1.1944 |
3.1944 |
Military Sealift Command 10.1949, stricken 7.1960 |
AKA56, 1.1969- LKA56 |
Arneb (ex-Mischief) |
246 |
Moore, Oakland |
1943 |
6.7.1943 |
11.1943 |
stricken 8.1971 |
AKA57, 1.1969- LKA57 |
Capricornus (ex-Spitfire) |
247 |
Moore, Oakland |
1943 |
14.8.1943 |
11.1943 |
stricken 1.1977 |
AKA58, 10.1949- T-AKA58 |
Chara |
252 |
Federal, Kearny |
1943 |
15.3.1944 |
6.1944 |
ammunition transport AE31 6.1966 |
AKA59 |
Diphda |
253 |
Federal, Kearny |
1944 |
11.5.1944 |
7.1944 |
stricken 1960? |
AKA60, 10.1949- T-AKA60 |
Leo |
254 |
Federal, Kearny |
3.1944 |
29.7.1944 |
8.1944 |
Military Sealift Command 10.1949, stricken 7.1960 |
AKA61, 1.1969- LKA61 |
Muliphen |
255 |
Federal, Kearny |
5.1944 |
26.8.1944 |
10.1944 |
stricken 1.1977 |
AKA62 |
Sheliak |
256 |
Federal, Kearny |
6/1944 |
17.10.1944 |
12.1944 |
stricken 5.1946 |
AKA63 |
Theenim |
257 |
Federal, Kearny |
7.1944 |
31.10.1944 |
12.1944 |
stricken 5.1946 |
AKA88 |
Uvalde (ex-Wild Pigeon) |
275 |
Moore, Oakland |
3.1944 |
20.5.1944 |
8.1944 |
stricken 7.1960, reinstated 9.1961, stricken 12.1968 |
AKA89 |
Warrick (ex-Black Prince) |
276 |
Moore, Oakland |
4.1944 |
29.5.1944 |
8.1944 |
stricken 7.1961 |
AKA90 |
Whiteside (ex-Wings of the Morning) |
277 |
Moore, Oakland |
4.1944 |
12.6.1944 |
9.1944 |
stricken ~1968 |
AKA91 |
Whitley |
278 |
Moore, Oakland |
5.1944 |
22.6.1944 |
9.1944 |
stricken 7.1960 |
AKA92, 1960s- T-AKA92 |
Wyandot |
279 |
Moore, Oakland |
5.1944 |
28.6.1944 |
9.1944 |
Military Sealift Command 1960s, cargo ship T-AK283 1.1969 |
AKA93, 1.1969- LKA93 |
Yancey |
280 |
Moore, Oakland |
5.1944 |
8.7.1944 |
10.1944 |
stricken 1.1977 |
AKA94, 1.1969- LKA94 |
Winston |
258 |
Federal, Kearny |
7.1944 |
30.11.1944 |
1.1945 |
stricken 9.1976 |
AKA95 |
Marquette |
259 |
Federal, Kearny |
1945 |
29.4.1945 |
6.1945 |
stricken 1.1960 |
AKA96 |
Mathews |
260 |
Federal, Kearny |
9.1944 |
22.12.1944 |
3.1945 |
stricken 11.1968 |
AKA97, 1.1969- LKA97 |
Merrick |
261 |
Federal, Kearny |
10.1944 |
28.1.1945 |
3.1945 |
stricken 9.1976 |
AKA98 |
Montague |
262 |
Federal, Kearny |
1944 |
12.2.1945 |
4.1945 |
stricken 2.1960 |
AKA99 |
Rolette |
263 |
Federal, Kearny |
12.1944 |
11.3.1945 |
4.1945 |
stricken 4.1947, reinstated 8.1951, stricken 7.1960 |
AKA100, 10.1949- T-AKA100 |
Oglethorpe |
264 |
Federal, Kearny |
12.1944 |
15.4.1945 |
6.1945 |
Military Sealift Command 10.1949, stricken 11.1968 |
Displacement standard, t |
8635 |
Displacement full, t |
13910 |
Length, m |
132.6 wl 139.9 oa |
Breadth, m |
19.2 |
Draught, m |
7.92 max |
No of shafts |
1 |
Machinery |
AKA15, 19, 20: 1 set General Electric geared steam turbines, 2 Combustion Engineering boilers AKA16, 17: 1 set De Laval geared steam turbines, 2 Combustion Engineering boilers AKA18, 53-63, 88-100: 1 set General Electric geared steam turbines, 2 Foster Wheeler boilers |
Power, h. p. |
6000 |
Max speed, kts |
16.5 |
Fuel, t |
oil 1553 |
Endurance, nm(kts) |
16046(12) |
Armament |
1 x 1 - 127/38 Mk 12, 4 x 2 - 40/56 Mk 1.2, (16 - 18) x 1 - 20/70 Mk 4 |
Electronic equipment |
presumably SF or SG or SH or SL or SO or SU radar |
Military load |
15 - 16 LCVP, 8 LCM(3), 1 LCP(L), 4450 t of cargo by 1945: 6 LCM(6), 2 LCM(3), 13 LCVP, 1 LCPL, ~4900 t of cargo, 74 - 78 marines |
Complement |
404 |
Project history: USN military transport vessels were sectioned into two groups: ÀÐ for transportation of troops and ÀÊ for carriage of goods and technics. The majority of them were built on the basis of standard types Ñ2, Ñ3 and Ñ4 and differed from usual cargo ships a little.
For delivery of troops and cargoes directly to a beaching place assault landing transport ships (ÀÐÀ and ÀÊÀ) served, which main difference from ÀÊ and ÀÐ consisted that they were extra equipped with disembarkation craft of LCVP, LCM and LCP (L) types; with their help delivery of people and cargoes to beach also was effected.
Originally similar ships were not outlined in own subclass and were registered as ÀÐ and ÀÊ. In February, 1943 reorganisation was done and assault transports have received indexation ÀÐÀ and ÀÊÀ.
Two ships of Doyen class, projected even on the eve of war for landing operations in Caribbean basin, became the first American assault military transports. The overwhelming majority of remaining ÀÐÀ and ÀÊÀ has been converted from merchant cargo and cargo-passenger vessels or constructed in hulls of standard cargo vessels built by the big series in days of war. An exception were specially projected as assault transports Gilliam (ÀÐÀ) and Artemis (ÀÊÀ) classes.
Besides the large landing transport ships of ÀÐÀ and ÀÊÀ classes, small landing parties and subversive groups were landed by fast landing transports (APD) converted from become outdated Wickes and Clemson classes destroyers and destroyer escorts of Buckley and Rudderow classes.
Andromeda class ships were built in standard type C2-S-B1 hulls.
Modernizations: None
.1/1946: 1 x 1 - 127/38 Mk 30, 4 x 2 - 40/60 Mk 1, (16 - 18) x 1 - 20/70 Mk 10, SF or SG or SH or SL or SO or SU radar
Naval service: Leo 27.2.1945 was damaged at Iwojima by gunfire of Japanese coastal batteries. Wyandot 28.3.1945 was damaged at Okinawa by Japanese aircraft. Achernar 2.4.1945 was damaged at Okinawa by kamikaze.
Chara
