No 126 1995
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| 126 | Jiangnan SY, China | 6.6.1995 | in service (2020) | ||||
| 127 | Jiangnan SY, China | 6.6.1995 | in service (2020) | ||||
| 128 | Jiangnan SY, China | 6.6.1995 | in service (2020) |
|
Displacement standard, t |
175 |
|
Displacement full, t |
210 |
|
Length, m |
39.0 |
|
Breadth, m |
7.70 |
|
Draught, m |
1.80 full load |
|
No of shafts |
3 |
|
Machinery |
3 type 42-160 diesels |
|
Power, h. p. |
12000 |
|
Max speed, kts |
36 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
800(30) |
|
Armament |
4 x 1 C-801 SSM (4 C-801), 1 x 2 QW-1 SAM (4 QW-1), 2 x 2 - 30/71 type 69 |
|
Sensors |
type 352C, type 347G radars |
|
Complement |
30 |
Project history: Chinese-built type 021 FACs. First was completed in 1993, but delivery was delayed by the the Yemeni civil war.
Modernizations: 2002, may be all: - 4 x 1 C-801 SSM
Naval service: All were presumably renumbered. One craft (former 128) ran aground in September 1997 but was salvaged. May be all are in poor condition and not armed with missiles today.
No 126 1995
No 1017 2009
