Sebago (as HMS Walney) 1942
Tampa (as HMS Banff) 1945
| No | Name | Yard No | Builder | Laid down | Launched | Comm | Fate |
| WPG45 | Chelan | 1411 | Fore River, Quincy | 11/1927 | 19.5.1928 | 9.1928 | to United Kindom 5.1941-2/1946 (Lulworth), sold 10.1947 |
| WPG46 | Pontchartrain | 1412 | Fore River, Quincy | 11/1927 | 16.6.1928 | 10.1928 | to United Kingdom 4.1941 (Hartland) |
| WPG47 | Tahoe | 1413 | Fore River, Quincy | 12/1927 | 12.6.1928 | 11.1928 | to United Kindom 4.1941-3/1946 (Fishguard), sold 10.1947 |
| WPG48, 3.1946- WPG319 | Champlain | 1414 | Fore River, Quincy | 5/1928 | 11.10.1928 | 1.1929 | to United Kindom 5.1941-3/1946 (Sennen), sold 3.1948 |
| WPG49 | Mendota | 1415 | Fore River, Quincy | 6/1928 | 27.11.1928 | 3.1929 | to United Kingdom 4.1941 (Culver) |
| WPG50, 4.1946- WPG321 | Itasca | General Engineering, Alameda | 16.11.1929 | 7.1930 | to United Kindom 5.1941-4/1946 (Gorleston), stricken 9.1950 | ||
| WPG51 | Sebago | General Engineering, Alameda | 2.10.1930 | 9.1930 | to United Kingdom 5.1941 (Walney) | ||
| WPG52, 2.1946- WPG164 | Saranac, 2.1946- Sebec, 5.1947- Tampa | General Engineering, Alameda | 12.4.1930 | 10.1930 | to United Kindom 4.1941-2/1946 (Banff), sold 2.1959 | ||
| WPG53 | Shoshone | General Engineering, Alameda | 11.9.1930 | 1/1931 | to United Kingdom 5.1941 (Landguard) | ||
| WPG54, 5.1946- WPG163 | Cayuga, 5.1946- Mocoma | 797 | Staten Island SB, Port Richmond | 7.10.1931 | 3.1932 | to United Kindom 5.1941-5/1946 (Totland), sold 7.1955 |
|
Displacement standard, t |
1662 trials |
|
Displacement full, t |
2075 |
|
Length, m |
72.9 wl 76.2 oa |
|
Breadth, m |
12.8 |
|
Draught, m |
3.94 trials |
|
No of shafts |
1 |
|
Machinery |
1 electric motor, 1 General Electric turbine-generator, 2 Babcock & Wilcox boilers |
|
Power, h. p. |
3350 |
|
Max speed, kts |
17 |
|
Fuel, t |
oil 300 |
| Endurance, nm(kts) | |
|
Armament |
1 x 1 - 127/51 Mk 7.8, 1 x 1 - 76/50 Mk 10, 2 x 1 - 57/50 Mk 8 |
|
Complement |
97 |
Project history:
Cutters intended for service in Northern
Atlantic (ice circumstances observation, for what their hulls were strengthened).
Machinery of the ships included spread enough
in the USA turbo-electric gear. They were differed good habitability for their
dimensions, however a number of the lacks was generic in them, not allowing to
consider them as rigorous combat ships: the hull had insufficient subdivision on
watertight compartments, bulkheads did not reach an upper deck which besides on
the big extent was wood (not steel, sheathed by a wood, and continuous wood as
by sailing frigates).
Modernizations: 1946,
1946, Chelan, Champlain, Mocoma were returned with armament: 1 x 1 - 102/45 CP Mk II, 1 x 1 - 76/45 Mk II, 2 x 1 - 40/39 Mk VIII, 4 x 1 - 20/70 Mk III, 1 x 24 - 178 Hedgehog Mk X ASWRL, 2 DCT, 2 DCR (100), presumably type 271 or type 277 radar
1946, Itasca was returned with armament: 1 x 1 - 102/45 CP Mk II, 1 x 1 - 40/60 Mk III, 4 x 1 - 40/39 Mk VIII, 4 x 1 - 20/70 Mk III, 1 x 24 - 178 Hedgehog Mk X ASWRL, 2 DCT, 2 DCR (100), presumably type 271 or type 277 radar
1946, Sebec was returned with armament: 1 x 1 - 102/45 CP Mk II, 3 x 1 - 76/45 Mk II, 7 x 1 - 20/70 Mk III, 1 x 24 - 178 Hedgehog Mk X ASWRL, 2 DCT, 2 DCR (100), presumably type 271 or type 277 radar
1947, Itasca, Tampa, Mocoma were presumably armed with 1 x 1 - 127/51 Mk 13, (2-3) x 1 - 76/50 Mk 21/22, (2-4) x 1 - 20/70 Mk 10, presumably type 271 or type 277 radar
Naval service: All ships of class were transferred to Royal Navy by lend-lease.
Tahoe
