Uruguay 2010
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Uruguay (ex-Comandante João Belo) | 1 | A C de Nantes, France | 6.9.1965 | 22.3.1966 | 1.7.1967 // 14.3.2008 | in service (2019) | |
| Comandante Pedro Campbell (ex-Comandante Sacadura Cabral) | 2 | A C de Nantes, France | 10.8.1967 | 15.3.1968 | 25.7.1969 // 8.4.2008 | stricken late 2018 |
|
Displacement standard, t |
1750 |
|
Displacement full, t |
2230 |
|
Length, m |
98.0 pp 102.7 oa |
|
Breadth, m |
11.8 |
|
Draught, m |
4.35 |
|
No of shafts |
2 |
|
Machinery |
4 SEMT-Pielstick 12PC2.2 V400 diesels |
|
Power, h. p. |
16000 |
|
Max speed, kts |
26 |
|
Fuel, t |
diesel oil 210 |
|
Endurance, nm(kts) |
7500(16) |
|
Armament |
2 x 1 - 100/55 Mle 1953, 2 x 1 - 40/60 Mk 3, 2 x 3 - 324 Mk 32 mod.5 TT (Mk 44) |
| Military load | 2 LCP, 80 marines |
|
Electronic equipment |
type 1007, DRBV-22A, DRBC-31D, DRBV-50 radars, SQS-510 sonar, AR-700 ECM suite, 2x Mk 36 SRBOC decoy RL, SLQ-25 Nixie torpedo decoy, SEWACO-FD CCS |
|
Complement |
159 |
Project history: Former Portuguese frigates of Commandant Riviere class.
Modernizations: None.
Naval service: Comandante Pedro Campbell was badly damaged by collision with Uruguay in May 2008 off South African coast bay later was repaired.
