TB14 1880
|
|
Displacement normal, t |
33 |
|
Displacement full, t |
|
|
Length, m |
26.2 oa 25.6 pp |
|
Breadth, m |
3.35 |
|
Draught, m |
1.35 |
|
No of shafts |
1 |
|
Machinery |
1 2-cyl VC, 1 locomotive boiler |
|
Power, h. p. |
550 |
|
Max speed, kts |
21.7 |
|
Fuel, t |
coal 5 |
|
Endurance, nm(kts) |
|
|
Armament |
1 x 1 - 406 TT (3) |
|
Complement |
15 |
hip project history: Generally considered the best of the batch, a good seaboat and fast (she made 16kts at sea in 1886), but her accommodation was very bad.
Modernizations: 1880s: - 1 x 1 - 406 TT; + 2 - 356 TC
Naval service: No significant events.
TB14
TB14
