| Name | No | Yard No | Builder | Laid down | Launched | Comp. | Fate |
| L713 | McTay Marine, Liverpool | 1986 | stricken 2003-2005 | ||||
| L714 | McTay Marine, Liverpool | 1986 | stricken 2003-2005 | ||||
| L715 | McTay Marine, Liverpool | 1986 | stricken 2003-2005 |
|
Displacement standard, t |
115 |
|
Displacement full, t |
160 |
|
Length, m |
25.7 |
|
Breadth, m |
6.50 |
|
Draught, m |
1.70 |
|
No of shafts |
2 |
|
Machinery |
2 Dorman 8JTM diesels |
|
Power, h. p. |
540 |
|
Max speed, kts |
10 (9 loaded) |
|
Fuel, t |
diesel oil |
| Endurance, nm(kts) | 300(9) |
|
Armament |
none |
|
Military load |
1-2 tanks or 100t of vehicles |
|
Complement |
7 |
Project history: LCU Mk 9 with new diesels and grill-reinforced bow ramps.
Modernizations: None.
Naval service: No significant events.
2003
