| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Sinop | White, Cowes, UK | 1858 | 1858 | 1860 | stricken 1901 | ||
| İzmir | White, Cowes, UK | 1858 | 1859 | 1859 | stricken 1879 | ||
| Bursa | Wigram, Blackwall, UK | 1858 | 1859 | 1859 | stricken 1899 | ||
| Edirne | Wigram, Blackwall, UK | 1858 | 1859 | 1859 | stricken 1901 |
|
Displacement normal, t |
769 - 787 |
|
Displacement full, t |
|
|
Length, m |
53.2 pp |
|
Breadth, m |
9.30 |
|
Draught, m |
4.50 |
|
No of shafts |
1 |
|
Machinery |
1 2-cyl HSE, 2 rectangular boilers |
|
Power, h. p. |
640 |
|
Max speed, kts |
10 - 11 |
|
Fuel, t |
coal 120 |
| Endurance, nm(kts) | |
|
Armament |
16 x 1 - 120/16 33pdr SBML |
|
Complement |
150 |
Project history: Wooden-hulled, ship-rigged sloops, these vessels were sheathed and coppered and featured raked masts and one funnel between the fore- and mainmasts.
Modernizations: 1885, all survived: were armed with 2 x 1 - 149/22 RK L/25 C/75, 2 x 1 - 120/22 RK L/22 C/78, 3 x 1 - 37/20 Hotchkiss, 2 x 1 - 25/42 Nordenfelt
1889, Sinop: was armed only with 3 x 1 - 50/22 SK L/25, 3 x 1 - 37/20 Hotchkiss
Naval service: No significant events.
Sinop 1890
© Ivan Gogin, 2014
