| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Edda | 260 | Örlogsvarvet Karlskrona | 30.11.1882 | 4.1885 | minelayer 1907, barrack ship 10.1923 |
|
Displacement normal, t |
613 |
|
Displacement full, t |
640 |
|
Length, m |
55.8 |
|
Breadth, m |
8.26 |
|
Draught, m |
3.10 |
|
No of shafts |
2 |
|
Machinery |
2 VC, boilers |
|
Power, h. p. |
960 |
|
Max speed, kts |
13.5 |
|
Fuel, t |
coal 80 |
| Endurance, nm(kts) | |
|
Armament |
1 x 1 - 274/23 K/26 M1881, 1 x 1 - 152/25 K/28 M1883, 2 x 1 - 25/32 K/35 M1884 |
|
Complement |
76 |
Project history: Coast defence gunboats, improvement of Blenda class.
Modernizations: 1907: - 1 x 1 - 274/23, 1 x 1 - 152/25, 2 x 1 - 25/32; + 4 x 1 - 57/50 K/55 M89B, mines
Naval service: no significant events.
Edda
Many thanks to Wolfgang Stöhr for additional information on this page.
