similar P451 1985
|
Names |
P463 P464 P465, late 1990s- P440, 2013- 46 P466, late 1990s- P441, 2013- 47 P467, late 1990s- P442, 2013- 48 P468, late 1990s- P443, 2013- 49 |
|
Builders |
Israeli Aircraft Industries, Be'er Sheva, Israel: P463-468 |
|
Commissioned |
1987: P463-466 1988: P467, 468 |
|
Losses |
P463 (Tamil Tigers 29.8.1995), P464 (Tamil Tigers 29.8.1993) |
|
Transfers |
None |
|
Discarding |
in service (2019): 46-49 |
|
Displacement standard, t |
48 |
|
Displacement full, t |
54 |
|
Length, m |
22.4 |
|
Breadth, m |
5.50 |
|
Draught, m |
1.80 |
|
No of shafts |
2 |
|
Machinery |
2 MTU 12V396 TB93 diesels |
|
Power, h. p. |
3260 |
|
Max speed, kts |
46 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
1200(17) |
|
Armament |
2 x 1 - 20/70 Mk 10, 2 x 1 - 12.7/90 |
|
Sensors |
Decca 926 radar |
|
Complement |
12 |
Project history: Israeli 'Super Dvora Mk I' class. Aluminium construction.
Modernizations: none.
Naval service: In 2013 all survived boats were transferred to Coast Guard.
1995
