| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Duque de Tetuán | Arsenal de Ferrol | 1874 | 1874 | discarded 1900 |
|
Displacement normal, t |
703 |
|
Displacement full, t |
|
|
Length, m |
43.0 |
|
Breadth, m |
9.50 |
|
Draught, m |
2.15 |
|
No of shafts |
2 |
|
Machinery |
|
|
Power, h. p. |
190 |
|
Max speed, kts |
6 |
|
Fuel, t |
coal 23 |
| Endurance, nm(kts) | |
|
Armour, mm |
iron; side: 100, battery: 100 |
|
Armament |
1 x 1 - 160/16 Parrot MLR, 4 x 1 - 121/12 SBML |
|
Complement |
60 |
Project history: Iron-hulled floating battery.
Ship protection: 100mm iron armour protected sides and battery.
Modernizations: None.
Naval service: No significant events.
Duque de Tetuán
© Ivan Gogin, 2014
