Zheleznyakov 1943
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Железняков [Zheleznyakov] | 300 Yd (Leninskaya Kuznitsa), Kiev | 11.1934 | 22.11.1935 | 10.1936 | hulk 3.1958 | ||
| Левачёв [Levachov] | 300 Yd (Leninskaya Kuznitsa), Kiev | 7.1934 | 1935 | 10.1936 | scuttled 18.9.1941 | ||
| Жемчужин [Zhemchuzhin] | 300 Yd (Leninskaya Kuznitsa), Kiev | 7.1934 | 1935 | 11.1936 | scuttled 12.8.1941 | ||
| Мартынов [Martynov] | 300 Yd (Leninskaya Kuznitsa), Kiev | 7.1934 | 1935 | 12.1936 | scuttled 18.9.1941 | ||
| Флягин [Flyagin] | 300 Yd (Leninskaya Kuznitsa), Kiev | 7.1934 | 1935 | 12.1936 | scuttled 18.9.1941 | ||
| Ростовцев [Rostovtsev] | 300 Yd (Leninskaya Kuznitsa), Kiev | 7.1934 | 1936 | 5.1937 | scuttled 18.9.1941 |
|
Displacement standard, t |
230 |
|
Displacement full, t |
263 |
|
Length, m |
51.2 |
|
Breadth, m |
8.20 |
|
Draught, m |
0.90 |
|
No of shafts |
2 |
|
Machinery |
2 4SD-19/32 diesels |
|
Power, h. p. |
280 |
|
Max speed, kts |
8.3 |
|
Fuel, t |
diesel oil 22 |
| Endurance, nm(kts) | 3700(8.3) |
| Armour, mm | belt: 16 - 4, deck: 4, bulkheads: 4, turret: 30, CT: 30 |
|
Armament |
1 x 2 - 102/43 MK-2-4, 2 x 1 - 45/43 40K, 2 x 1 - 7.6/94 |
|
Complement |
78 |
Project history: Development of SB-30 project. The basic difference consisted in the immovable conning tower mounted on 750mm tube, reduction of armour thickness and using of less powerful diesels. Thanks to increased length it was possible to moderate draught.
Ship protection: Hull had only bulletproof protection, turret and CT were protected by 30mm armour.
Modernizations: 1940, all: - 1 x 1 - 45/43; + 1 x 2 - 45/43 41K, 1 x 4 - 7.6/94.
1942 - 1943, Zheleznyakov: - 1 x 4 - 7.6/94; + 2 x 1 - 37/63 70K, 3 x 1 - 12.7/79
1944, Zheleznyakov: - 1 x 1 - 12.7/79; + 1 x 4 - 12.7/62
Naval service: All losses were on Dnepr. Zhemchuzhin 11.8.1941 was damaged in battle against German field artillery and tanks, when ammunition was expended, 12.8.1941 she was blown up by crew at settlement Voronovka. Levachev, Rostovtsev and Flyagin 18.9.1941 were blown up near Kiev, and Martynov in the same day on river Konskaya at Blagoveshchensk near Nikopol. Rostovtsev in 1945 was repaired as training vessel and stricken in September, 1950, she was scrapped in 1955. Zheleznyakov 11.3.1958 was disarmed and converted to hulk, since 10.7.1967 she was preserved in Kiev as monument.
Zheleznyakov as memorial ship
