Yorsh 1875
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| ¨ðø [Yorsh] | New Admiralty, St. Petersburg | 10.1873 | 17.8.1874 | 1875 | stricken 8.1907 |
|
Displacement normal, t |
321 |
|
Displacement full, t |
|
|
Length, m |
29.6 wl 30.1 oa |
|
Breadth, m |
8.69 |
|
Draught, m |
2.23 max |
|
No of shafts |
2 |
|
Machinery |
2 HC, 2 cylindrical boilers |
|
Power, h. p. |
240 |
|
Max speed, kts |
8 |
|
Fuel, t |
coal |
| Endurance, nm(kts) | |
|
Armament |
1 x 1 - 279/17 obr. 1867 |
|
Complement |
44 |
Project history: Composite-hulled, with the 279mm mounted as a pivot gun on a descending platform and training 12° each side of the keel line by means of a steam capstan.
Modernizations: 1879: + 2 x 1 - 44/41 Ängström
1900: armament consisted of 4 x 1 - 87/21 4pdr obr. 1877
Naval service: No significant events.
Yorsh
© Ivan Gogin, 2014
