Zheleznyakov 2010
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Железняков [Zheleznyakov] | 901 | 561 | Sredne-Nevskiy SYd, Pontonnyy | 28.2.1985 | 17.7.1986 | 30.12.1988 | in service (2019) |
| Владимир Гуманенко [Vladimir Gumanenko] | 811 | 562 | Sredne-Nevskiy SYd, Pontonnyy | 15.9.1985 | 4.3.1991 | 2000 | in service (2019) |
| --- | 563 | Sredne-Nevskiy SYd, Pontonnyy | 1986 | --- | --- | suspended 1991 |
|
Displacement standard, t |
1070 |
|
Displacement full, t |
1150 |
|
Length, m |
67.8 |
|
Breadth, m |
11.0 |
|
Draught, m |
3.12 |
|
No of shafts |
2 |
|
Machinery |
2 M-503B-37 diesels |
|
Power, h. p. |
5000 |
|
Max speed, kts |
15.7 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
1500(12) |
|
Armament |
2 x 4 Strela-3 SAM (16 9M36), 1 x 1 - 76/59 AK-176M, 1 x 6 - 30/54 AK-630M, 16 mines, 2 x 4 - 400 Giurza mine countermeasures system launchers, Ketmen', Paltus USVs, KTK-1 mechanical, TEM-3M magnetic, AT-3 acoustic minesweeping gear, ShZ-3 mine clearance line charges |
|
Electronic equipment |
MR-123-01 Vympel-A, 2x MR-212/201 Vaygach-U radars, MG-99 Kabarga-A3, MG-7 Braslet sonars, 2x PK-16 decoy RL |
|
Complement |
68 |
Project history: Oceangoing minesweeper intended to use new mine countermeasures systems as Giurza anti-mine expendable drones, Ketmen' and Paltus USVs.
Modernizations: 2016, Vladimir Gumanenko: - MG-7 Braslet sonar; + MG-757.1 Anapa sonar
Naval service: No significant events.
Vladimir Gumanenko 2002
