BDK-10 large landing ships (project 1171) (1966 - 1975)

Voronezhskiy Komsomolets 1970

Donetskiy Shakhtyor 1979

Nikolay Vilkov 1979

Nikolay Vilkov 1980

Saratov 2015

Nikolay Vilkov 2015

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
group 1
БДК-10 [BDK-10], 2.1967- Воронежский комсомолец [Voronezhskiy Komsomolets], 2.1992- БДК-65 [BDK-65], 7.2003- Саратов [Saratov]	150	291	Yantar', Kaliningrad	5.2.1964	1.7.1964	18.8.1966	in service (2019)
БДК-6 [BDK-6], 11.1970- Крымский комсомолец [Krymskiy Komsomolets], 2.1992- БДК-6 [BDK-6]		292	Yantar', Kaliningrad	4.7.1964	15.2.1965	30.12.1966	stricken 3.1992
БДК-13 [BDK-13], 6.1972- Томский комсомолец [Tomskiy Komsomolets], 2.1992- БДК-25 [BDK-25]		293	Yantar', Kaliningrad	18.2.1965	26.3.1966	30.9.1967	stricken 7.1994
БДК-62 [BDK-62], 9.1981- Комсомолец Карелии [Komsomolets Karelii], 2.1992- БДК-62 [BDK-62]		294	Yantar', Kaliningrad	5.8.1966	1.3.1967	29.12.1967	stricken 12.1997
group 2
БДК-66 [BDK-66], 2.1975- Сергей Лазо [Sergey Lazo]		295	Yantar', Kaliningrad	7.3.1967	28.8.1967	27.9.1968	stricken 7.1994
БДК-69 [BDK-69], 10.2002- Орск [Orsk]	148	296	Yantar', Kaliningrad	30.8.1967	29.2.1968	31.12.1968	in service (2019)
group 3
БДК-77 [BDK-77], 10.1972- 50 лет шефства ВЛКСМ [50 Let Shefstva VLKSM], 2.1992- БДК-80 [BDK-80]		297	Yantar', Kaliningrad	12.3.1968	31.8.1969	30.9.1969	stricken 7.1994
Донецкий шахтёр [Donetskiy Shakhtyor]		298	Yantar', Kaliningrad	5.9.1968	10.3.1969	31.12.1969	stricken 4.2002
Красная Пресня [Krasnaya Presnya] (ex-БДК-100 [BDK-100])		299	Yantar', Kaliningrad	18.3.1969	11.10.1969	30.9.1970	stricken 6.1993
БДК-104 [BDK-104], 5.1982- Илья Азаров [Ilya Azarov]		300	Yantar', Kaliningrad	17.10.1969	31.3.1970	10.6.1971	to Ukraine 1.1996 (Рiвне [Rivne])
Александр Торцев [Aleksandr Tortsev]		301	Yantar', Kaliningrad	6.4.1970	27.11.1970	31.12.1971	stricken 7.1994
Пётр Ильичёв [Piotr Ilyichov]		302	Yantar', Kaliningrad	30.11.1970	30.8.1971	29.12.1972	stricken 6.1993
group 4
Николай Вилков [Nikolay Vilkov]	081	303	Yantar', Kaliningrad	30.9.1971	30.11.1973	30.7.1974	in service (2019)
Николай Фильченков [Nikolay Filchenkov]	152	304	Yantar', Kaliningrad	30.1.1974	29.3.1975	30.12.1975	in service (2019)
Николай Голубец [Nikolay Golubets]		305	Yantar', Kaliningrad	---	---	---	cancelled

Displacement standard, t	3040
Displacement normal, t	4650
Length, m	113.1
Breadth, m	15.6
Draught, m	4.50
No of shafts	2
Machinery	291-296: 2 58A diesels 297-302: 2 58A-3 diesels 303-305: 2 58A-4 diesels
Power, h. p.	9000
Max speed, kts	16.5
Fuel, t	diesel oil
Endurance, nm(kts)	4800(16)
Armament	291, 292, 295-297: 1 x 2 - 57/75 ZIF-31B 293, 294: 1 x 2 - 57/75 ZIF-31B, 2 x 1 - 45/69 21KM 298-300, 302: 1 x 2 - 57/75 ZIF-31B, 2 x 40 - 122 MS-73 Grad M RL 301: 1 x 2 - 57/75 ZIF-31B, 2 x 1 - 45/69 21KM, 2 x 40 - 122 MS-73 Grad M RL 303-305: 1 x 2 - 57/75 ZIF-31B, 2 x 2 - 25/112 2M-3M, 2 x 40 - 122 MS-73 Grad M RL
Military load	291-296: 20 medium tanks or 47 AFV or 52 trucks, 313 troops 297-305: 20 medium tanks or 47 AFV or 52 trucks, 440 troops
Electronic equipment	1 - 2 Don radars
Complement	69

Project history: All designed by TsKB-50.

Soviet designation, BDK, large landing ship. These ships have bow and stern ramps for unloading vehicles, and are essentially of freighter configuration. Can carry 1500t of cargo. Early units have three cranes (15t and two 5t); later ships have only one crane. Later units have an enclosed bridge and a RL forward.

Modernizations: 1970s, Voronezhskiy Komsomolets, Krymskiy Komsomolets, Tomskiy Komsomolets, BDK-69, 50 Let Shefstva VLKSM, Donetskiy Shakhtyor, Krasnaya Presnya, BDK-104, Aleksandr Tortsev, Nikolay Vilkov, Nikolay Filchenkov: + 3 x 2 Strela-3 SAM (24 9M36)

1970s, Piotr Ilyichov: + 2 x 2 Strela-3 SAM (16 9M36)

1980s, Nikolay Vilkov: + 2 x 7 - 55 MRG-1 GL

1980s, Tomskiy Komsomolets: + 2 x 1 - 45/69 21KM

1990s, BDK-65: + MR-231 Pal radar

Naval service: No significant events.

Aleksandr Tortsev 1976

Orsk 2003
