ATAMAN PLATOV landing craft (project 21280) (2010-2015)
Ataman Platov 2010
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Атаман Платов [Ataman Platov] (ex-Д-105 [D-105]) | 728 | 811 | Volga, Nizhniy Novgorod | 21.2.2006 | 7.2009 | 2010 | in service (2019) |
| Иван Карцов [Ivan Kartsov] | 685 | 4001 | Vostochnaya verf', Vladivostok | 2010 | 30.9.2013 | 11.6.2015 | in service (2019) |
| Денис Давыдов [Denis Davydov] | 758 | 701 | SSZ Yaroslavl' | 18.1.2012 | 26.7.2013 | 23.11.2014 | in service (2019) |
| Лейтенант Римский-Корсаков [Leytenant Rimskiy-Korsakov] | 754 | 702 | SSZ Yaroslavl' | 21.6.2012 | 10.4.2014 | 4.7.2015 | in service (2019) |
| Мичман Лермонтов [Michman Lermontov] | 757 | 703 | SSZ Yaroslavl' | 18.1.2013 | 5.6.2014 | 4.7.2015 | in service (2019) |
|
Displacement standard, t |
|
|
Displacement normal, t |
280 |
|
Length, m |
45.0 |
|
Breadth, m |
8.60 |
|
Draught, m |
2.20 |
|
No of shafts |
2 |
|
Machinery |
2 M507A-2-010M3 diesels |
|
Power, h. p. |
20000 |
|
Max speed, kts |
40 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
|
|
Armament |
2 x 1 - 14.5/89 |
|
Military load |
3 main battle tanks or 5 APCs and 50 troops or 1 tank and 90 troops or 140 t cargo |
|
Electronic equipment |
Pal-N-3 radar |
|
Complement |
6 |
Project history: Twice enlarged project 11770 (Serna) became project Dyugon'. Semiplating hull incorporates an air cavity to provide underhull lubrication. Aluminium alloy construction.
Modernizations: None.
Naval service: No significant events.
Denis Davydov 2014
