STEREGUSHCHIY corvettes (project 20380) (2007-)
GREMIASHCHIY corvettes (project 20385)
Steregushchiy 2015
Soobrazitelnyy 2015
Gremiashchiy
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Project 20380 | |||||||
| Стерегущий [Steregushchiy] | 550 | 1001 | Severnaya verf', St. Petersburg | 21.12.2001 | 16.5.2006 | 14.11.2007 | in service (2019) |
| Сообразительный [Soobrazitelnyy] | 531 | 1002 | Severnaya verf', St. Petersburg | 20.5.2003 | 31.3.2010 | 14.10.2011 | in service (2019) |
| Бойкий [Boykiy] | 532 | 1003 | Severnaya verf', St. Petersburg | 27.7.2005 | 15.4.2011 | 16.5.2013 | in service (2019) |
| Стойкий [Stoykiy] | 545 | 1004 | Severnaya verf', St. Petersburg | 10.11.2006 | 30.5.2012 | 18.7.2014 | in service (2019) |
| Ретивый [Retivyy] | 1007 | Severnaya verf', St. Petersburg | 20.2.2015 | 2019 | 2020 | building (2019) | |
| Строгий [Strogiy] | 1008 | Severnaya verf', St. Petersburg | 20.2.2015 | 2020 | 2021 | building (2019) | |
| Совершенный [Sovershennyy] | 333 | 2101 | Amurskiy SSZ, Komsomolsk-on-Amur | 30.6.2006 | 22.5.2015 | 20.7.2017 | in service (2019) |
| Громкий [Gromkiy] | 335 | 2102 | Amurskiy SSZ, Komsomolsk-on-Amur | 20.4.2012 | 28.7.2017 | 25.12.2018 | in service (2019) |
| Герой Российской Федерации Алдар Цыденжапов [Geroy Rossiyskoy Federatsii Aldar Tsydenzhapov] | 2103 | Amurskiy SSZ, Komsomolsk-on-Amur | 22.7.2015 | 2019 | 2020 | building (2019) | |
| Резкий [Rezkiy] | 2104 | Amurskiy SSZ, Komsomolsk-on-Amur | 1.7.2016 | 2020 | 2021 | building (2019) | |
| Project 20385 | |||||||
| Гремящий [Gremiashchiy] | 1005 | Severnaya verf', St. Petersburg | 1.2.2012 | 30.6.2017 | 2019 | building (2019) | |
| Проворный [Provornyy] | 1006 | Severnaya verf', St. Petersburg | 25.7.2013 | 2019 | 2020 | building (2019) | |
| 2105 | Amurskiy SSZ, Komsomolsk-on-Amur | 2019 | 2020 | 2021 | ordered (2019) | ||
| 2106 | Amurskiy SSZ, Komsomolsk-on-Amur | 2019 | 2020 | 2021 | ordered (2019) | ||
|
Displacement standard, t |
1900 |
|
Displacement full, t |
pr. 20380: 2200 pr. 20385: 2300 |
|
Length, m |
pr. 20380: 111.6 pr. 20385: 115.1 |
|
Breadth, m |
14.0 |
|
Draught, m |
3.70 hull 5.00 max |
|
No of shafts |
2 |
|
Machinery |
4 16D49 diesels |
|
Power, h. p. |
23320 |
|
Max speed, kts |
27 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
4000(14) |
|
Armament |
pr. 20380, 1001: 2 x 4 Uran SSM (8 3M24), 1 x (8 Kortik-M SAM + 2 x 6 - 30/54) Kortik-M CADS (64 9M311), 1 x 8 Igla SAM (32 9M39), 1 x 1 - 100/59 A-190-01, 2 x 6 - 30/54 AK-630M-06, 2 x 1 - 14.5/89, 2 x 4 - 330 Paket-NK TT, 2 x 2 - 45 DP-64 grenade launchers, 1 helicopter (Ka-27) pr. 20380, others: 2 x 4 Uran SSM (8 3M24), 3 x 4 Redut SAM (VLS, 12 9M96 or 48 9M100), 1 x 8 Igla SAM (32 9M39), 1 x 1 - 100/59 A-190-01, 2 x 6 - 30/54 AK-630M-06, 2 x 1 - 14.5/89, 2 x 4 - 330 Paket-NK TT, 2 x 2 - 45 DP-64 grenade launchers, 1 helicopter (Ka-27) pr. 20385: 1 x 8 Kalibr-NK SSM/CruM (VLS, 8 3M14/3M54), 4 x 4 Redut SAM (VLS, 16 9M96 or 64 9M100), 1 x 1 - 100/59 A-190-01, 2 x 6 - 30/54 AK-630M-06, 2 x 1 - 14.5/89, 2 x 4 - 330 Paket-NK TT, 2 x 2 - 45 DP-64 grenade launchers, 1 helicopter (Ka-27) |
|
Sensors |
pr. 20380: 5P-20K-A Monument-A, 5P-27M Furke-2, 2x Sandal-V, MR-231, MR-231-3, Pal-N, 5P-10-02 Puma-02, MR-123-02 radars, Sfera-02, 2x MTK-201M E/O detectors, Zaria-2, Minotavr-ISPN-M, MG-757 Anapa-M sonars, TK-25-2 ECM suite, 4x PK-10 Smelyy decoy launchers, Sigma-20380 CCS pr. 20385: 5P-20K-A Monument-A, 5P-27M Furke-2, 2x Sandal-V, MR-231, MR-231-3, Pal-N, MR-123-02 radars, Sfera-02, 2x MTK-201M E/O detectors, Zaria-2, Minotavr-ISPN-M, MG-757 Anapa-M sonars, TK-25-2 ECM suite, 8x KT-216 decoy launchers (Prosvet-M system), Sigma-20380 CCS |
|
Complement |
99 |
Project history: Design was approved by the Navy in 2001. Steel hull with composite superstructure, with form shaped to reduce radar interference. Helicopter hangar has weapon reload and fuelling capability. Some sources signed Nos 1002-1004, 1007, 1008 and 2101-2104 as project 20381 but this designation is wrong. Ships of the project 20385 will can carry also Yakhont hypersonic SSMs.
Modernizations: None.
Naval service: Soobrazitelnyy was damaged by collision 2.9.2012 and was under repair to May 2013.
Steregushchiy 2007
Soobrazitelnyy 2011
