SOVIET/RUSSIA NAVY (USSR/RUSSIA)

ESCORTS

PLK-4 ASW ships (project 159) (1961 - 1966)

SKR-16 guard ships (project 159A) (1967 - 1972)

SKR-95 guard ships (project 159AE) (1968 - 1978)

PLK-14 1962

SKR-38 1979

SKR-29 1979

SKR-47 1979

SKR-34 1979

SKR-106 1991

SKR-38 1987

Name No Yard No Builder Laid down Launched Comp Fate
Project 159
ÏËÊ-4 [PLK-4], 5.1966- ÑÊÐ-38 [SKR-38]   150 820 Yd, Kaliningrad 31.10.1958 1.4.1960 30.11.1961 stricken 4.1990
ÏËÊ-5 [PLK-5], 5.1966- ÑÊÐ-47 [SKR-47]   151 820 Yd, Kaliningrad 31.12.1958 1.7.1960 26.12.1961 stricken 10.1992
ÏËÊ-14 [PLK-14], 5.1966- ÑÊÐ-26 [SKR-26]   153 820 Yd, Kaliningrad 6.3.1959 1.6.1960 27.12.1961 stricken 6.1993
ÏËÊ-17 [PLK-17], 5.1966- ÑÊÐ-17 [SKR-17]   154 820 Yd, Kaliningrad 24.4.1959 5.8.1960 31.12.1961 test vessel OS-34 8.1982, stricken 9.1990
ÏËÊ-9 [PLK-9], 5.1966- ÑÊÐ-9 [SKR-9]   157 820 Yd, Kaliningrad 18.7.1959 14.10.1960 30.6.1962 stricken 4.1990
ÏËÊ-22 [PLK-22], 5.1966- ÑÊÐ-22 [SKR-22]   158 820 Yd, Kaliningrad 26.9.1959 25.1.1961 14.11.1962 stricken 6.1991
ÏËÊ-25 [PLK-25], 5.1966- ÑÊÐ-33 [SKR-33]   159 820 Yd, Kaliningrad 26.12.1959 7.4.1961 14.11.1962 stricken 8.1995
ÏËÊ-27 [PLK-27], 5.1966- ÑÊÐ-27 [SKR-27]   162 820 Yd, Kaliningrad 8.4.1960 29.5.1961 31.12.1962 stricken 7.1992
ÏËÊ-30 [PLK-30], 5.1966- ÑÊÐ-30 [SKR-30]   163 820 Yd, Kaliningrad 15.6.1960 24.6.1961 31.12.1962 test vessel OS-333 3.1978, stricken 9.1990
ÏËÊ-34 [PLK-34], 5.1966- ÑÊÐ-34 [SKR-34]   165 820 Yd, Kaliningrad 27.7.1960 30.8.1961 4.10.1963 stricken 4.1990
ÏËÊ-37 [PLK-37], 5.1966- ÑÊÐ-40 [SKR-40]   166 820 Yd, Kaliningrad 28.10.1960 18.11.1961 30.6.1964 stricken 1.1994
ÏËÊ-1 [PLK-1], 5.1966- ÑÊÐ-1 [SKR-1]   601 Krasny Metallist, Zelenodolsk 31.8.1957 31.8.1959 30.12.1961 test vessel OS-332 3.1978, stricken 10.1986
ÏËÊ-15 [PLK-15], 5.1966- ÑÊÐ-18 [SKR-18]   28 Khabarovsk SYd 28.8.1959 27.6.1961 12.12.1962 stricken 5.1989
ÏËÊ-41 [PLK-41], 5.1966- ÑÊÐ-41 [SKR-41]   29 Khabarovsk SYd 27.2.1960 1.7.1962 21.3.1963 stricken 6.1987
ÏËÊ-11 [PLK-11], 5.1966- ÑÊÐ-11 [SKR-11]   30 Khabarovsk SYd 20.12.1960 25.4.1963 14.12.1963 stricken 2.1991
ÏËÊ-43 [PLK-43], 5.1966- ÑÊÐ-43 [SKR-43]   31 Khabarovsk SYd 16.6.1961 28.8.1963 29.4.1964 stricken 5.1989
ÏËÊ-3 [PLK-3], 5.1966- ÑÊÐ-3 [SKR-3]   32 Khabarovsk SYd 10.1.1962 29.5.1964 26.12.1964 stricken 4.1990
ÏËÊ-46 [PLK-46], 5.1966- ÑÊÐ-46 [SKR-46]   33 Khabarovsk SYd 19.7.1963 24.4.1965 30.9.1965 stricken 5.1989
ÏËÊ-23 [PLK-23], 5.1966- ÑÊÐ-23 [SKR-23]   34 Khabarovsk SYd 23.12.1963 20.8.1965 30.12.1965 stricken 5.1989
Project 159A
ÑÊÐ-29 [SKR-29] (ex-ÏËÊ-29 [PLK-29])   186 Yantar, Kaliningrad 10.12.1964 27.3.1966 30.12.1966 stricken 6.1991
ÑÊÐ-16 [SKR-16], 4.1991- Áàêèíåö [Bakinets]   187 Yantar, Kaliningrad 4.12.1964 21.7.1966 25.7.1967 to Azerbaijan 9.1992 (Bakılı)
ÑÊÐ-103 [SKR-103]   188 Yantar, Kaliningrad 27.3.1966 15.12.1966 29.9.1967 stricken 6.1991
ÑÊÐ-106 [SKR-106]   189 Yantar, Kaliningrad 26.7.1966 26.3.1967 30.11.1967 stricken 6.1993
ÑÊÐ-110 [SKR-110]   190 Yantar, Kaliningrad 20.12.1966 7.5.1967 30.12.1967 test vessel OS-226 4.1991, stricken 7.1994
ÑÊÐ-112 [SKR-112]   191 Yantar, Kaliningrad 26.4.1967 15.8.1967 30.5.1968 mutiny 21.7.1992, escaped to Ukraine (ÑÊÐ-112 [SKR-112])
ÑÊÐ-115 [SKR-115]   192 Yantar, Kaliningrad 20.8.1966 4.11.1967 27.8.1968 to Ethiopia 3.1984 (F1617)
ÑÊÐ-98 [SKR-98]   196 Yantar, Kaliningrad 8.12.1967 4.1.1969 30.9.1969 stricken 1.1991
ÑÊÐ-94 [SKR-94], 10.1972- Êðàñíîäàðñêèé êîìñîìîëåö [Krasnodarskiy Komsomolets]   197 Yantar, Kaliningrad 25.3.1968 22.10.1969 30.12.1969 to Ethiopia 7.1983 (ዘራዕ ደረስ [Zerai Deres])
ÑÊÐ-87 [SKR-87], 5.1990- Êîìñîìîëåö Äàãåñòàíà [Komsomolets Dagestana]   198 Yantar, Kaliningrad 6.6.1968 5.11.1968 14.8.1969 stricken 7.1992
ÑÊÐ-120 [SKR-120]   199 Yantar, Kaliningrad 19.6.1969 7.4.1970 29.9.1970 stricken 6.1991
ÑÊÐ-123 [SKR-123]   211 Yantar, Kaliningrad 23.10.1969 5.6.1970 30.11.1970 stricken 10.1992
ÑÊÐ-126 [SKR-126]   212 Yantar, Kaliningrad 29.1.1970 22.9.1970 30.12.1970 stricken 7.1992
ÑÊÐ-78 [SKR-78] (ex-ÏËÊ-59 [PLK-59])   35 Khabarovsk SYd 29.10.1964 29.4.1966 31.12.1966 stricken 4.1990
ÑÊÐ-21 [SKR-21] (ex-ÏËÊ-21 [PLK-21]), 3.1979- Îðëîâñêèé êîìñîìîëåö [Orlovskiy Komsomolets]   36 Khabarovsk SYd 29.12.1964 30.6.1966 31.12.1966 stricken 2.1991
ÑÊÐ-36 [SKR-36]   37 Khabarovsk SYd 31.8.1965 27.4.1967 30.9.1967 stricken 5.1989
ÑÊÐ-92 [SKR-92]   38 Khabarovsk SYd 28.3.1966 31.7.1967 30.12.1967 stricken 6.1991
ÑÊÐ-88 [SKR-88]   41 Khabarovsk SYd autumn 1966 --- --- cancelled 8.1967
ÑÊÐ-130 [SKR-130]   44 Khabarovsk SYd 11.9.1969 5.9.1970 30.9.1970 to Vietnam 12.1983 (HQ15)
ÑÊÐ-133 [SKR-133]   45 Khabarovsk SYd 22.12.1969 5.9.1970 31.12.1970 stricken 2.1994
ÑÊÐ-138 [SKR-138]   46 Khabarovsk SYd 14.4.1970 15.5.1971 30.9.1971 stricken 2.1994
ÑÊÐ-141 [SKR-141]   47 Khabarovsk SYd 30.4.1970 7.8.1971 31.12.1971 to Vietnam 12.1983 (HQ13)
ÑÊÐ-128 [SKR-128]   48 Khabarovsk SYd 3.3.1971 3.6.1972 30.9.1972 stricken 6.1991
ÑÊÐ-135 [SKR-135]   49 Khabarovsk SYd 15.8.1971 12.8.1972 26.12.1972 to Vietnam 12.1984 (HQ17)
Project 159AE
ÑÊÐ-100 [SKR-100]   193 Yantar, Kaliningrad 28.8.1967 14.3.1968 30.11.1968 to India 5.1972 (अर्नला [Arnala])
ÑÊÐ-104 [SKR-104]   194 Yantar, Kaliningrad 4.10.1967 23.4.1968 25.12.1968 to India 5.1972 (अमिनि [Amini])
ÑÊÐ-108 [SKR-108]   195 Yantar, Kaliningrad 18.11.1967 24.6.1968 31.12.1968 to India 9.1972 (अंजदिप [Anjadip])
ÑÊÐ-95 [SKR-95]   39 Khabarovsk SYd 10.3.1967 15.5.1968 27.9.1968 to Syria 3.1969 (الحراسة [Al Hirasa])
ÑÊÐ-82 [SKR-82]   96 Khabarovsk SYd 22.1.1975 28.4.1976 14.5.1977 to Vietnam 12.1978 (HQ09)
ÑÊÐ-96 [SKR-96]   97 Khabarovsk SYd 27.6.1975 25.4.1976 29.6.1978 to Vietnam 12.1978 (HQ11)



Displacement standard, t

pr. 159: 910

pr. 159A: 970

pr. 159AE: 1000

Displacement normal, t

pr. 159: 1050

pr. 159A: 1110

pr. 159AE: 1140

Length, m

pr. 159: 81.8

pr. 159A, 159AE: 82.3

Breadth, m

9.20

Draught, m

pr. 159: 2.77 mean 5.82 max

pr. 159A: 2.89 mean 5.92 max

pr. 159AE: 2.93 mean 5.96 max

No of shafts

3

Machinery

pr. 159: CODAG, 2 M-2 gas turbines + 1 47B-16 diesel

pr. 159A: CODAG, 2 M-2B gas turbines + 1 61B diesel

pr. 159AE: CODAG, 2 M-2BE gas turbines + 1 61B-2 diesel

Power, h. p.

pr. 159, 159A: 36000 (30000+6000)

pr. 159AE: 29400 (24000+5400)

Max speed, kts

pr. 159, 159A: 32

pr. 159AE: 29

Fuel, t

oil

Endurance, nm(kts)

pr. 159, 159A: 2000(14)

pr. 159AE: 1800(14)

Armament

pr. 159: 2 x 2 -76/59 AK-726, 1 x 5 - 400 TT, 4 x 16 RBU-2500 Smerch ASWRL, 1 DCR, 22 mines

pr. 159A: 2 x 2 - 76/59 AK-726, 2 x 5 - 400 TT, 2 x 12 RBU-6000 Smerch-2 ASWRL, 1 DCR, 22 mines

pr. 159AE: 2 x 2 - 76/59 AK-726, 1 x 3 - 533 TT, 2 x 12 RBU-6000 Smerch-2 ASWRL, 1 DCR, 22 mines

Sensors

pr. 159: Fut-N, Fut-B, Don radars, MG-312 Titan, MG-311 Vychegda sonars, Bizan'-4B ECM suite

pr. 159A: MR-302 Rubka, Fut-B, Don radars, MG-312 Titan, MG-311 Vychegda sonars, Bizan'-4B ECM suite

pr. 159AE: Fut-N, Fut-B, Don radars, MG-312IE Titan, MG-311 Vychegda sonars, Bizan'-4B ECM suite

Complement

pr. 159: 98

pr. 159A, 159AE: 106

Project history: Designation changed from small ASW ship (PLK) to guard ship (SKR) 19.5.1966.

    These were the first Soviet warships specially designated as ASW units. Like Project 61, they were developed under the 1956 directive. The first large Soviet gas turbine combatant, Project 159 was powered by a pair of M-2s plus a diesel. Project 35 was a similar hull in which a pair of jet engines in raised spaces exhausting directly aft rather than geared to propeller shafts.

Modernizations: 1964, PLK-5; 1968, SKR-30; 1974, SKR-46; 1977, SKR-23; 1979, SKR-22; 1980, SKR-33; 1981, SKR-26, SKR-43; 1987, SKR-38 - under Project 159M: 1040/1180t, 82.3x9.20x3.01(6.04)m; - 2 x 16 RBU-2500 ASWRL, 1 DCR, Fut-N radar (on some); + MR-302 Rubka radar (on some instead of Fut-N), MG-325 Vega sonar (VDS), MI-110K wake detector (on some)

1966, SKR-40 - under Project 159AB: - 1 x 2 - 76/59, 2 x 16 RBU-2500 ASWRL; + MG-325 Vega sonar (VDS)

1970, SKR-23, SKR-46, SKR-33: - 1 x 5 - 400 TT

1970s, some Project 159A: - 1 x 5 - 400 TT; + MG-325 Vega sonar (VDS)

1976, SKR-34 - under Project 159AV: - 1 x 2 - 76/59, 1 x 5 - 400 TT, 2 x 16 RBU-2500 ASWRL; + MNK-300 Kayra non-acoustic submarine detecting system

1978, SKR-98: + MG-345 Bronza sonar

Naval service: As test vessels OS-332 was used for test of Vikhr' ASuM, OS-333 used for tests of non-acoustic submarine detectors, OS-34 tested Avrora-N sonar.

Project 159A 1978
