NEUSTRASHIMYY guard ships (project 11540) (1993-2009)
Neustrashimyy 2010
Yaroslav Mudryy 2010
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Неустрашимый [Neustrashimyy] | 772 | 401 | Yantar', Kaliningrad | 25.3.1987 | 25.5.1988 | 28.12.1990 | in service (2019) |
| Ярослав Мудрый [Yaroslav Mudryy] (ex-Неприступный [Nepristupnyy]) | 777 | 402 | Yantar', Kaliningrad | 27.5.1988 | 6/1990 | 19.7.2009 | in service (2019) |
| Туман [Tuman] | 403 | Yantar', Kaliningrad | 1993 | --- | --- | suspended 1995 |
|
Displacement standard, t |
3950 |
|
Displacement full, t |
4350 |
|
Length, m |
129.8 |
|
Breadth, m |
15.6 |
|
Draught, m |
4.80 hull 8.35 max |
|
No of shafts |
2 |
|
Machinery |
COGAG M27: 2 M70 cruising gas turbines + 2 M90 boost gas turbines |
|
Power, h. p. |
57000 (20000 + 37000) |
|
Max speed, kts |
29 |
|
Fuel, t |
gas turbine oil |
|
Endurance, nm(kts) |
3000(18) |
|
Armament |
401: 1 x 4 Kinzhal SAM VLS (32 9M330), 2 x (8 Kortik SAM + 2 x 6 - 30/54) Kortik CIWS (64 9M311), 6 x 1 URPK-6 Vodopad-NK SSM/ASuM (6 83R and 84R), 1 x 1 - 100/59 AK-100, 1 x 12 RBU-6000 RPK-8 ASWRL, 16 - 20 mines, 1 helicopter (Ka-27) 402: 4 x 4 Uran SSM (8 3M24), 1 x 4 Kinzhal SAM VLS (32 9M330), 2 x (8 Kortik SAM + 2 x 6 - 30/54) Kortik CIWS (64 9M311), 6 x 1 URPK-6 Vodopad-NK SSM/ASuM (6 83R and 84R), 1 x 1 - 100/59 A-190, 2 x 1 - 12.7/79, 1 x 12 RBU-6000 RPK-8 ASWRL, 2 x 10 - 55 DP-65(RG-55M) grenade launchers, 16 - 20 mines, 1 helicopter (Ka-27) |
|
Sensors |
401: MR-750 Fregat-M2, K-12-1, MR-145 Lev-218-100, MR-212 Vaygach radars, MGK-365 Zvezda-M1 sonar suite, MP-405-1 ECM suite, 2x PK-16, 8x PK-10 Smelyy decoy RLs, Tron-11540 CCS 402: MR-750 Fregat-M2, K-12-1, MR-145 Lev-218-100, MR-212 Vaygach radars, Korall satellite-based targeting system, MGK-365 Zvezda-M1 sonar suite, TK-25 ECM suite, 2x PK-16, 8x PK-10 Smelyy decoy RLs, Tron-11540 CCS |
|
Complement |
210 |
Project history: This is the Project 1135 successor. Like Project 11351, it is intended to fire a surface-ship variant of the standard submarine ASW stand-off missile. The elimination of special ASW missile tubes leaves space aft for helicopter. Missiles and torpedoes are fired from catapults. The sonar suite consisted of bow, flank and towed VDS arrays.
Modernizations: 2015, Neustrashimyy: - MGK-365 Zvezda-M1 sonar suite; + Zaria-SK sonar suite
Naval service: No significant events.
Neustrashimyy 2002
Neustrashimyy 2008
