¹206 1904
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Ñâåàáîðã [Sveaborg] (ex-¹5), 1.1898- ¹205 | Normand, Le Havre, France | 6/1885 | 1.10.1886 | 11/1886 | dispatch vessel 7.1911, stricken 8.1913 | ||
| Ðåâåëü [Revel'] (ex-¹6), 1.1898- ¹206 | Normand, Le Havre, France | 6/1885 | 8/1886 | 10/1886 | dispatch vessel 7.1911, stricken 8.1913 |
|
Displacement normal, t |
Sveaborg: 96 Revel': 108 |
|
Displacement full, t |
|
|
Length, m |
46.8 |
|
Breadth, m |
Sveaborg: 3.43 Revel': 3.73 |
|
Draught, m |
Sveaborg: 2.64 Revel': 2.51 |
|
No of shafts |
1 |
|
Machinery |
1 VTE, 1 Normand boiler |
|
Power, h. p. |
Sveaborg: 737 Revel': 837 |
|
Max speed, kts |
Sveaborg: 19.2 Revel': 19.7 |
|
Fuel, t |
coal 29 |
| Endurance, nm(kts) | 1500(12.5) |
|
Armament |
2 x 5 - 37/17 Hotchkiss, 2 - 381 TT (bow, 4) |
|
Complement |
21 |
Project history: Very satisfactory boats with two fixed bow TT. They were later shipped to Vladivostok in sections.
Modernizations: 1911, both: - 2 x 5 - 37/17, 2 - 381 TT; + 2 x 1 - 47/40 Hotchkiss
Naval service: No significant events.
