RUSSIAN NAVY (RUSSIA)

COASTAL FORCES

P-104 patrol boats (project 21980) (2009-)

P-104 2010

Name No Yard No Builder Laid down Launched Comp Fate
П-104 [P-104], 12.2013- Нахимовец [Nakhimovets] 689 981 SSZ im. Gorkogo, Zelenodolsk 8.2.2008 25.4.2009 11.2009 in service (2019)
П-191 [P-191], 2.2015- Кадет [Kadet] 840 982 SSZ im. Gorkogo, Zelenodolsk 7.5.2010 7.2011 10.2011 in service (2019)
П-349 [P-349], 2.2015- Суворовец [Suvorovets] 841 983 SSZ im. Gorkogo, Zelenodolsk 6.5.2011 16.6.2012 14.11.2012 in service (2019)
П-350 [P-350], 2.2015- Курсант-Кировец [Kursant-Kirovets] 850 984 SSZ im. Gorkogo, Zelenodolsk 5.5.2012 4.2013 22.8.2013 in service (2019)
П-351 [P-351], 8.2016- Юнармеец Каспия [Yunarmeets Kaspiya] 600 985 SSZ im. Gorkogo, Zelenodolsk 27.7.2012 2013 15.10.2013 in service (2019)
П-355 [P-355], 8.2016- Юнармеец Крыма [Yunarmeets Kryma] 836 986 SSZ im. Gorkogo, Zelenodolsk 7.5.2013 5.2014 22.8.2014 in service (2019)
П-424 [P-424], 6.2-17- Кинель [Kinel'] 837 987 SSZ im. Gorkogo, Zelenodolsk 27.7.2013 2014 9.10.2014 in service (2019)
П-433 [P-433] 844 988 SSZ im. Gorkogo, Zelenodolsk 12.1.2015 17.5.2017 16.9.2017 in service (2019)
Юнармеец Татарстана [Yunarmeets Tatarstana] 601 989 SSZ im. Gorkogo, Zelenodolsk 7.5.2015 2018 2018 in service (2019)
    990 SSZ im. Gorkogo, Zelenodolsk 2016 2018 2019 building (2019)
П-377 [P-377] 996 8002 Vostochnaya verf', Vladivostok 15.3.2012 24.6.2013 26.9.2013 in service (2019)
П-420 [P-420], 8.2016- Юнармеец Приморья [Yunarmeets Primorya] 997 8003 Vostochnaya verf', Vladivostok 2012 30.11.2013 24.2.2014 in service (2019)
П-417 [P-417], 8.2016- Юнармеец Камчатки [Yunarmeets Kamchatki] 994 8004 Vostochnaya verf', Vladivostok 2012 4.7.2014 25.9.2014 in service (2019)
П-431 [P-431], 2.2019- Юнармеец Чукотки [Yunarmeets Chukotki] 995 8005 Vostochnaya verf', Vladivostok 2016 8.2017 14.10.2017 in service (2019)
П-... [P-...]   8006 Vostochnaya verf', Vladivostok 2017 12.10.2018 12.2018 in service (2019)
    8007 Vostochnaya verf', Vladivostok 2016 2018 2019 building (2019)
Юнармеец Заполярья [Yunarmeets Zapoliarya] (ex-П-340 [P-340]) 669 01221 Vympel, Rybinsk 3.2014 7.6.2016 19.11.2016 in service (2019)
П-421 [P-421], 2018- Юнармеец Беломорья [Yunarmeets Belomorya] 699 01222 Vympel, Rybinsk 12.2014 22.7.2016 19.11.2016 in service (2019)
П-429 [P-429] 936 01223 Vympel, Rybinsk 15.9.2015 27.4.2017 14.7.2017 in service (2019)
П-430 [P-430], 2.2018- Валерий Федянин [Valeriy Fedyanin] 941 01224 Vympel, Rybinsk 15.4.2016 22.6.2017 9.11.2017 in service (2019)
БСК-... [BSK-...]   01225 Vympel, Rybinsk 2017 2019 2019 building (2019)
БСК-... [BSK-...]   01226 Vympel, Rybinsk 2017 2019 2019 building (2019)
БСК-... [BSK-...]   01227 Vympel, Rybinsk 2017 2019 2019 building (2019)
БСК-... [BSK-...]   01228 Vympel, Rybinsk 2017 2019 2019 building (2019)







Displacement standard, t

138

Displacement full, t

140

Length, m

31.0

Breadth, m

7.40

Draught, m

1.85

No of shafts

2

Machinery

981-987, 8002-8004: 2 MTU diesels

988-990, 8005-8007, 01221-01226: 2 TBD620V12 diesels

Power, h. p.

4800

Max speed, kts

23

Fuel, t

diesel oil

Endurance, nm(kts)

200(23)

Armament

1 x 4 Igla SAM (12 9M39), 1 x 1 - 14.5/89, 1 x 10 - 55 DP-65A grenade launcher, 1 x 1 - 45 DP-64 grenade launcher, 1 Falkon UAV

Sensors

MR-231 radar, MTK-201M3 E/O detector, Kalmar, MG-757 Anapa-M sonars, P-104 Filin E/O countermeasures system

Complement

8 + swimmers

Project history: Intended for local port and harbor protection missions, counterterrorism and diver support, carry compression chamber.

Modernizations: None.

Naval service: No significant events.

P-424 2016
