BK-101 1944
BK-318 1944
|
Names |
№11 [No11], 2.1944- БК-11 [BK-11] №11 [No11], 6.1942- №41 [No41], 8.1942- №51 [No51], 11.1942- №31 [No31] №12 [No12], 2.1944- БК-12 [BK-12] №12 [No12], 6.1942- №42 [No42], 8.1942- №52 [No52], 11.1942- №72 [No72] №13 [No13], 2.1944- БК-13 [BK-13] №14 [No14], 2.1944- БК-14 [BK-14] №14 [No14], 6.1943- №114 [No114] №15 [No15], 2.1944- БК-15 [BK-15] №15 [No15], 6.1943- №121 [No121], 3.1944- БК-121 [BK-121] №16 [No16], 6.1943- №122 [No122] №21 [No21], 2.1944- БК-21 [BK-21] №21 [No21], 6.1942- №43 [No43], 8.1942- №53 [No53], 11.1942- №32 [No32], 2.1944- БК-32 [BK-32] №22 [No22], 2.1944- БК-22 [BK-22] №23 [No23], 6.1942- №44 [No44], 8.1942- №54 [No54], 11.1942- №33 [No33], 3.1944- БК-33 [BK-33] №23 - 25 [No23 - 25], 2.1944- БК-23 - 25 [BK-23 - 25] №31 [No31], 8.1942- №32 [No32], 9.1942- №111 [No111], 11.1942- №73 [No73] №32 [No32], 8.1942- №33 [No33], 9.1942- №112 [No112], 11.1942- №75 [No75], 3.1944- БК-75 [BK-75] №41 [No41], 2.1944- БК-41 [BK-41] №41 Капитан 3 ранга Лысенко [No41 Kapitan 3 ranga Lysenko], 9.1942- №91 Капитан 3 ранга Лысенко [No91 Kapitan 3 ranga Lysenko], 2.1943- №213 Капитан 3 ранга Лысенко [No213 Kapitan 3 ranga Lysenko], 3.1944- БК-215 Капитан 3 ранга Лысенко [BK-215 Kapitan 3 ranga Lysenko] №42 [No42], 2.1944- БК-42 [BK-42] №42 За Сталинград [No42 Za Stalingrad], 9.1942- №92 За Сталинград [No92 Za Stalingrad], 2.1943- №214 За Сталинград [No214 Za Stalingrad] №43 [No43], 2.1944- БК-43 [BK-43] №43 [No43], 9.1942- №64 [No64], 2.1943- №221 [No221], 3.1944- БК-221 [BK-221] №44 - 46 [No44 - 46], 2.1944- БК-44 - 46 [BK-44 - 46] №51 - 55 [No51 - 55], 2.1944- БК-51 - 55 [BK-51 - 55] №61 [No61], 2.1944- БК-61 [BK-61] №61 [No61], 4.1942- №11 [No11], 8.1942- №31 [No31], 9.1942- №113 [No113], 11.1942- №71 [No71], 3.1944- БК-71 [BK-71] №62 - 66 [No62 - 66], 2.1944- БК-62 - 66 [BK-62 - 66] №67 [No67], 10.1938- №56 [No56], 2.1944- БК-56 [BK-56] №97 [No97] №98 [No98] №99 [No99], 12.1944- БК-99 [BK-99] №100 [No100], 12.1944- БК-100 [BK-100] №101 [No101], 2.1944- БК-101 [BK-101] №101 [No101], 9.1942- №11 [No11], 6.1943- №111 [No111], 3.1944- БК-111 [BK-111] №102 [No102], 2.1944- БК-102 [BK-102] №103 [No103], 9.1942- №13 [No13], 6.1943- №113 [No113] №211 [No211], 3.1944- БК-211 [BK-211] №212 [No212], 3.1944- БК-212 [BK-212] №314 [No314], 3.1944- БК-314 [BK-314] №324 [No324], 3.1944- БК-324 [BK-324] №411 [No411], 3.1944- БК-411 [BK-411] №412 [No412], 3.1944- БК-412 [BK-412] №413 Мститель [No413 Mstitel], 3.1944- БК-413 Мститель [BK-413 Mstitel] №414 [No414] №421 [No421] №423 [No423], 3.1944- БК-423 [BK-423] №424 [No424], 3.1944- БК-424 [BK-424] №431 - 434 [No431 - 434], 3.1944- БК-431 - 434 [BK-431 - 434] БК-20 [BK-20] БК-47 [BK-47] БК-48 [BK-48] БК-67 [BK-67] БК-103 [BK-103] БК-115 [BK-115] БК-154 [BK-154] БК-158 - 160 [BK-158 - 160] БК-161 Речник Кубани [BK-161 Rechnik Kubani] БК-162 Ейский Патриот BK-162 Eyskiy Oatriot] БК-163 Саратовский Патриот [BK-163 Saratovskiy Patriot] БК-164 Болградец [BK-164 Bolgradets] БК-165 Измаилец [BK-165 Izmailets] БК-308 Трудящийся Татарии [BK-308 Trudyashchiysya Tatarii] БК-309 [BK-309] БК-310 [BK-310] БК-318 - 320 [BK-318 - 320] БК-335 - 339 [BK-335 - 339] БК-343 [BK-343] БК-344 [BK-344] БК-346 [BK-346] БК-422 Сталинец [BK-422 Stalinets] БК-435 [BK-435] БК-436 [BK-436], 8.1949- БК-436 Герой Советского Союза Голубец [BK-436 Geroy Sovetskogo Soyuza Golubets] БК-437 [BK-437] |
|
Builders |
340 Yd, Zelenodolsk: No11(i), 11(ii), 12(i), 12(ii), 13, 14(i), 15(i), 21(i), 21(ii), 22(i), 22(ii), 23 - 25, 31, 32, 41(i), 42(i), 43(i), 44 - 46, 51 - 55, 61(i), 61(ii), 62(i), 62(ii), 63 - 66, 67, 211, 212, 411, 412, 423, 424, 431 - 434, BK-20, 47, 48, 67, 154, 158 - 160, BK-308 Trudyashchiysya Tatarii, BK-309, 310, BK-422 Stalinets 264 Yd, Stalingrad: No41(ii) Kapitan 3 ranga Lysenko, 42(ii) Za Stalingrad, 43(ii) 363 Yd, Leningrad: No97 - 100, 101(i), 102(i), BK-103 638 Yd, Astrakhan: No14(ii), 15(ii), 16, 101(ii), 102(ii), 103, 314, 324, 413 Mstitel, 414, BK-115, BK-161 Rechnik Kubani, BK-162 Eyskiy Patriot, BK-163 Saratovskiy Patriot, BK-164 Bolgradets, BK-165 Izmailets, BK-318 - 320, 335 - 339, 343, 435, BK-436 Geroy Sovetskogo Soyuza Golubets, BK-437 Ship Repair Yd, Novosibirsk: BK-344, 346 |
|
Commissioned |
1936: No12(i), 14(i), 41(i), 42(i), 43(i), 44 - 46, 51 - 54, 61(i), 62(i), 63 - 67 1937: No11(i), 13, 24, 55 1938: No15(i), 21(i), 22(i), 23, 25 1941: No11(ii), 12(ii), 21(ii), 22(ii), 31, 32, 61(ii), 62(ii), 97 - 100, 101(i), 102(i) 1942: No14(ii), 15(ii), 16, 101(ii), 102(ii), 103 1943: No41(ii) Kapitan 3 ranga Lysenko, 42(ii) Za Stalingrad, 43(ii), 211, 212, 314, 324, 411, 412, 413 Mstitel, 414, 421, 423, 424, 431 - 434, BK-335 - 338 1944: BK-20, 47, 103, 115, 154, 158 - 160, BK-161 Rechnik Kubani, BK-162 Eyskiy Patriot, BK-163 Saratovskiy Patriot, BK-164 Bolgradets, BK-165 Izmailets, BK-308 Trudyashchiysya Tatarii, BK-309, 310, 318 - 320, 339, 343, BK-422 Stalinets, BK-435, 437 1945: BK-48, 67, 436 1946: BK-344, 346 |
|
Losses |
No31 (13.11.1943), No72 (19.10.1943), No114 (31.10.1943), No122 (30.8.1943), No73 (1944), No214 Za Stalingrad (2.11.1943), No97 (30.8.1941), No98 (25.7.1941), BK-112 (26.8.1944), No113 (20.9.1943), BK-413 (10.5.1944), No414 (2.11.1943), No421 (7.11.1943), BK-424 (16.10.1944), BK-161 Rechnik Kubani (5.4.1945), BK-338 (9.12.1944) |
|
Transfers |
Bulgaria, 1951: BK-344, 346 |
|
Discarding |
1949/60: BK-11 - 15, 20 - 25, 41 - 48, 51 - 56, 61 - 67, 75, 99 - 103, 158 - 160, 165, 211, 212, 215, 308 - 310, 318 - 320, 324, 336, 339, 343, 344, 411 - 412, 423, 432, 433, 435, 437 to Board Guard 1945: BK-111, 121, 339 1949: BK-32, 33 1956: BK-221, 337 1957: BK-115, 154, 314, 335, 422, 434 1958: BK-71 1960: BK-161, 162, 431, 436 |
|
Displacement standard, t |
37 boats completed from 1940: 39 later boats: 44 |
|
Displacement full, t |
41 boats completed from 1940: 44 later boats: 48 - 52 |
|
Length, m |
25.3 |
|
Breadth, m |
3.59 later boats: 4.04 |
|
Draught, m |
0.80 later boats: 0.85 - 0.90 |
|
No of shafts |
2 |
|
Machinery |
2 GAM-34BS petrol engines |
|
Power, h. p. |
1500 |
|
Max speed, kts |
21 later boats: 18 |
|
Fuel, t |
petrol 4.2 |
| Endurance, nm(kts) | 280(13.5) |
|
Armour, mm |
belt: 7, deck: 4, turrets: 45 - 30, CT: 8 |
|
Armament |
2 x 1 - 76/15 L-10, 1 x 2 - 12.7/79 or 1 x 1 - 12.7/79 or 1 x 2 - 7.6/94, 2 x 1 - 7.6/94 boats completed since 1940: 2 x 1 - 76/40 F-34 (most) or 2 x 1 - 76/22 L-11 (few), 1 x 2 - 12.7/90 or 1 x 2 - 12.7/79 or 1 x 1 - 12.7/79, 2 x 1 - 7.6/94 some boats completed in 1940 - 1942: 2 x 1 - 76/28 8K, 1 x 2 - 12.7/79 or 1 x 1 - 12.7/79 or 1 x 2 - 7.6/94 some boats completed since 1942: 1 x 1 - 76/40 F-34 or 1 x 1 - 76/22 L-11 or 1 x 1 - 76/28 8K, 1 x 16 - 132 M-13 RL or 1 x 24 - 82 M-8 RL, 1 x 2 - 12.7/79 or 1 x 1 - 12.7/79, (0 - 1) x 1 - 7.6/94 boats completed since 1945: 2 x 1 - 76/40 F-34, 1 x 1 - 37/63 70K, 1 x 2 - 12.7/79, 2 x 1 - 7.6/94 1946: 2 x 1 - 76/42 F-34, 1 x 1 - 37/73 70K, 1 x 2 - 12.7/79, 2 x 1 - 7.6/94 |
|
Complement |
17 |
Project history: Designed in 1934 under guidance of Yu. Yu. Benua. In 1936 the lead boat passed trials and
mass production started. Boats were intended for service on Amur, but were used on various theatres, both rivers, and seas. They had armoured citadel and deck house;
machinery consisted of two aviation motors. Boats were armed by two turrets from
T-28 or BT-7A tanks. The AA armament under the design included a cupola with
twin 12.7mm MG, but because of low rates of issuance of the latter considerable
part of boats was armed by 1 single 12.7mm or 1 twin 7.62mm MGs instead.
Since 1940 as standard armament turrets from T-34 tank with regular 76mm/41.5 guns (part of boats received turrets
with 76mm/24 guns) were accepted. Displacement has thus increased to 38.6/43.8t. At expense of improved motors
endurance grown to 365nm. However in 1940-1942 in connection with cessation of issuance of
T-28 tank turrets and deficiency of T-34 tank turrets part of boats was armed by 2 76mm/30
Lender AA guns. Since 1942 some boats instead of aft turret received 1 24-rail 82mm
rocket launcher or 1 16-rail 132mm rocket launcher. Subsequently for deck wetness reduction wider clearing bar was established, the breadth thus increased to 3.96 m. Since 1945 serial
boats additionally received 37mm MG. Total displacement of boats by the war end grown till 48-52t.
Ship protection: Hull and CT had bullet-proof protection, guns placed in standard tank turrets. 76/30mm 8K guns were on open mounts without shields.
Modernizations: many boats were re-armed by various schemes, mostly as presented in the table.
Naval service: No significant events.
No221
