Doha
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| ضحى [Doha] | Fincantieri, Muggiano/Riva Trigoso, Italy | 27.11.2018 | 2020 | 2021 | building (2020) | ||
| ii | Fincantieri, Muggiano/Riva Trigoso, Italy | 2020 | 2021 | 2022 | ordered (2020) | ||
| iii | Fincantieri, Muggiano/Riva Trigoso, Italy | 2021 | 2022 | 2023 | ordered (2020) | ||
| iv | Fincantieri, Muggiano/Riva Trigoso, Italy | 2022 | 2023 | 2024 | ordered (2020) |
|
Displacement standard, t |
|
|
Displacement full, t |
3250 |
|
Length, m |
107.0 |
|
Breadth, m |
14.7 |
|
Draught, m |
4.20 |
|
No of shafts |
2 |
|
Machinery |
4 MAN 22/38D diesels |
|
Power, h. p. |
42900 |
|
Max speed, kts |
28 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
3500(15) |
|
Armament |
2 x 4 MM40 Exocet SSM (8 MM40 Block 3), 2 x 8 Aster 30 SAM (16 ASter 30), 1 x 21 RAM SAM (21 RIM-116), 1 x 1 - 76/62 Leonardo-OTO Super Rapid, 2 x 1 - 30/82 Marlin WS-30, 1 helicopter (NFH90) |
|
Sensors |
Kronos Grand 3D, NA-30S Mk 2, nav. radars, Medusa, SASS IRST e/o systems, Black Snake, Thesan sonars, Virgilius ECM suite, 2x Sylena Mk 2 decoy RL, Athena CCS |
|
Complement |
112 |
Project history: ABM design of Fincantieri, ordered in 2016.
Modernizations: None.
Naval service: No significant events.
Doha
