Bartolomeu Dias 2010
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Bartolomeu Dias (ex-Van Nes) | F333 | De Schelde, Vlissingen, Netherlands | 10.1.1990 | 16.5.1992 | 2.6.1994 // 16.1.2009 | in service (2019) | |
| Dom Francisco de Almeida (ex-Van Galen) | F334 | De Schelde, Vlissingen, Netherlands | 7.6.1990 | 21.11.1992 | 1.12.1994 // 15.1.2010 | in service (2019) |
|
Displacement standard, t |
2800 |
|
Displacement full, t |
3320 |
|
Length, m |
114.4 pp 122.3 oa |
|
Breadth, m |
13.1 wl 14.4 oa |
|
Draught, m |
4.30 hull 6.20 sonar |
|
No of shafts |
2 |
|
Machinery |
CODOG: 2 Roll-Royce Spey RM1C gas turbines / 2 Werkspoor-Wärtsilä 12SW280 V12 diesels |
|
Power, h. p. |
48900 / 9800 |
|
Max speed, kts |
30 |
|
Fuel, t |
diesel / gas turbine oil |
|
Endurance, nm(kts) |
5000(18) |
|
Armament |
2 x 4 Harpoon SSM (8 RGM-84A/C), 1 x 16 Sea Sparrow SAM (VLS, 16 RIM-7M), 1 x 1 - 76/62 OTO-Melara Compact SR, 1 x 7 - 30/87 Goalkeeper, 2 x 1 - 12.7/90, 4 - 324 Mk 32 TT (Mk 46 Mod.5), 1 helicopter (Super Lynx Mk 95) |
|
Electronic equipment |
Decca 1690/9, Scout, SMART-S, LW-08, 2x STIR 1.8, Goalkeeper radars, LR-IRSCAN e/o system, PHS-36(HSA), Anaconda (provision for) sonars, AR-700, 2x APECS II ECM suites, 2x Mk 36 SRBOC decoy RL, SLQ-25 Nixie torpedo decoy, SEWACO VIIB CCS |
|
Complement |
164 |
Project history: Van Nes was transferred 1.12.2008 followed by Van Galen 1.11.2009. Originally known as "M" (Karel Doorman) class.
Modernizations: None.
Naval service: No significant events.
Dom Francisco de Almeida 2009
