Alamgir 2010
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| عالمگیر [Alamgir] (ex-McInerney) | F260 | General Dynamics Bath Iron Works, USA | 16.1.1978 | 4.11.1978 | 15.12.1979 // 31.8.2010 | in service (2019) |
|
Displacement standard, t |
3010 |
|
Displacement full, t |
4100 |
|
Length, m |
125.9 wl 138.8 oa |
|
Breadth, m |
13.7 |
|
Draught, m |
5.80 mean 6.70 max |
|
No of shafts |
1 |
|
Machinery |
2 General Electric LM-2500 gas turbines |
|
Power, h. p. |
40000 |
|
Max speed, kts |
29 |
|
Fuel, t |
gas turbine oil 587 |
| Endurance, nm(kts) | 5000(18) |
|
Armament |
1 x 1 - 76/62 Mk 75, 2 x 1 - 25/75 Mk 38 Bushmaster, 1 x 6 - 20/76 Mk 15 Phalanx, 4 x 1 - 12.7/90, 2 x 3 - 324 Mk 32 TT, 2 helicopters (Alouette III) |
|
Electronic equipment |
SPS-55, SPS-49(V)4, Mk 92 Mod.4, Mk 90, Furuno radars, SQQ-89(V)2 sonar suite (SQS-56 hull-mounted sonar + SQR-19(V)2 towed array), SLQ-32(V)2 ECM suite, 2x Mk 36 SRBOC, 2x Nulka decoy RL, SLQ-25 Nixie torpedo decoy, NTDS CCS |
|
Complement |
248 |
Project history: Former USN frigate of Oliver H. Perry class, transferred without missile launcher.
Modernizations: ~2015: + 2 x 4 Harpoon SSM (8 RGM-84A)
Naval service: No significant events.
Alamgir 2013
