Names |
OJR1 - 6 H7, 8 |
|
Builders |
Higgins, New Orleans, USA: OJR1 - 6, H7, 8 |
|
Completed |
12/1941: OJR1 - 4 2/1942: OJR5, 6 8/1942: H7, 8 |
|
Losses |
OJR1 (2.3.1942), OJR2 (2.3.1942), OJR3 (2.3.1942), OJR4 (2.3.1942), OJR5 (2.3.1942), OJR6 (2.3.1942) |
|
Transfers |
None |
|
Discarding |
1/1946: H7, 8 |
|
Displacement standard, t |
48 |
|
Displacement full, t |
|
|
Length, m |
21.3 |
|
Breadth, m |
5.02 |
|
Draught, m |
1.42 deep load |
|
No of shafts |
OJR1 - 6: 4 H7, 8: 2 |
|
Machinery |
OJR1-6: 4 petrol engines H7, 8: 2 petrol engines |
|
Power, h. p. |
2600 |
|
Max speed, kts |
24 |
|
Fuel, t |
petrol |
| Endurance, nm(kts) | |
|
Armament |
OJR1 - 6: 2 x 1 - 12.7/90, 2 DCR (16) H7, 8: 1 x 1 - 20/70 Mk 4, 2 x 1 - 12.7/90, 2 DCT (16) |
| Electronic equipment | presumably QCU sonar |
|
Complement |
12 |
Project history: Ordered for service in the Dutch East Indies, built by Higgins in New Orleans in MTB hulls, but with less powerful motors and replacement of torpedoes by anti-submarine armaments. Boats were transferred to Surabaya onboard of merchant vessels (last two carried, OJR5 and 6, were never commissioned).
Modernizations: None.
Naval service: One of them (OJR1 or OJR4) was raised by Japanese and commissioned by IJN as auxiliary chaser Cha111, she was lost 8.4.1945.
H8
