Names |
3 units |
|
Builders |
CMN, Cherbourg, France: 3 units |
|
Completed |
2016: 3 units |
|
Losses |
None |
|
Transfers |
none |
|
Discarding |
in service (2020): 3 units |
|
Displacement standard, t |
75 |
|
Displacement full, t |
|
|
Length, m |
43.6 |
|
Breadth, m |
15.7 |
|
Draught, m |
1.60 |
|
No of shafts |
2 |
|
Machinery |
4 Scania DI13 070M diesels |
|
Power, h. p. |
2000 |
|
Max speed, kts |
30 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
5000(12) |
|
Armament |
1 x 1 - 20/90 Narwhal, 2 x 1 - 12.7/90, 1 UAV (S-100 Camcopter) |
|
Electronic equipment |
Raytheon radar, e/o system |
|
Complement |
8 + 8 passengers |
Project history: Composite construction, trimaran hull was built by H2X at La Ciotat. Have landing deck for helicopter-type UAV and ramp aft for 7m RIB.
Modernizations: None.
Naval service: No significant events.
2015
