Daegu 1980
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| 대구 [Daegu] (ex-Wallace L. Lind) | 97, 1980- 917 | Federal, Kearny, USA | 14.2.1944 | 14.6.1944 | 8.9.1944 // 3.12.1973 | stricken 1994 | |
| 인천 [Incheon] (ex-De Haven) | 98, 1980- 918 | Bath Iron Wks, USA | 9.8.1943 | 9.1.1944 | 31.3.1944 // 4.12.1973 | stricken 1993 |
|
Displacement standard, t |
2350 |
|
Displacement full, t |
3320 |
|
Length, m |
112.5 wl 114.8 oa |
|
Breadth, m |
12.5 |
|
Draught, m |
4.30 |
|
No of shafts |
2 |
|
Machinery |
2 sets General Electric geared steam turbines, 4 Babcock & Wilcox boilers |
|
Power, h. p. |
60000 |
|
Max speed, kts |
33.4 |
|
Fuel, t |
oil 497 |
|
Endurance, nm(kts) |
3300 (20) |
|
Armament |
3 x 2 - 127/38 Mk 38, 2 x 3 - 324 TT, 2 x 24 - 178 Hedgehog Mk 11 ASWRL, 1 DCR |
|
Electronic equipment |
97: SPS-10, SPS-40, Mk 25 radars, SQS-29, SQA-10 sonars, WLR-1 ECM suite, 2x decoy RL 98: SPS-10, SPS-37, Mk 25 radars, SQS-29 sonar, WLR-1 ECM suite, 2x decoy RL |
|
Complement |
235 |
Project history: Former USN Allen M. Sumner class destroyers, modernized under the FRAM II programme in 1960s. Hangar and flight deck, previously for DASH drone, were later converted to carry Alouette III helicopter.
Modernizations: 1976, Incheon: + 1 x 3 - 20/76 Sea Vulcan
1978, both: + Alouette III helicopter (hangar and flight deck were widened and strengthened)
1978-1979, both: + 2 x 2 Harpoon SSM (4 RGM-84)
early 1980s, both: + 2 x 2 - 40/60 Mk 1
Naval service: No significant events.
