similar Atago 2010
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| まや [Maya] | DDG179 | Japan Marine United, Yokohama | 17.4.2017 | 30.7.2018 | 2020 | building (2019) | |
| DDG180 | Japan Marine United, Yokohama | 23.1.2018 | 2019 | 2021 | building (2019) |
data is speculative
|
Displacement standard, t |
8200 |
|
Displacement full, t |
11400 |
|
Length, m |
169.9 oa |
|
Breadth, m |
21.0 |
|
Draught, m |
6.20 hull |
|
No of shafts |
2 |
|
Machinery |
COGLAG: 2 General Electric LM-2500 gas turbines, 2 gas turbine generators, 2 electric motors |
|
Power, h. p. |
100000 |
|
Max speed, kts |
30 |
|
Fuel, t |
gas turbine oil |
| Endurance, nm(kts) | 4500(20) |
|
Armament |
2 x 4 SSM-1B SSM (8 SSM-1B), (1 x 64 + 1 x 32) Standard SM-2MR SAM / ASROC VLA ASuR Mk 41 (VLS, 96 RIM-66 / x4 RIM-162 / RUM-139), 1 x 1 - 127/54 Mk 45 mod. 4, 2 x 6 - 20/76 Mk 15 Phalanx Block 1B, 2 x 3 - 324 HOS-302 TT, 2 helicopters (SH-60J) |
|
Electronic equipment |
SPY-1D(v), OPS-28E, 3x SPG-62, FCS-2-21, OPS-20, 2x Mk 90 radars, Mk 46 e/o director, SQQ-89(v) sonar, NOLQ-2B, OLT-3 ECM suites, 4x Mk 36 SRBOC decoy RL, SLQ-25 Nixie torpedo decoy, OYQ-6 CCS |
|
Complement |
307 |
Project history: Advanced Atago with new propulsion plant and new sonar suite.
Modernizations: None.
Naval service: No significant events.
