JAPAN MARITIME SELF-DEFENSE FORCE (JAPAN)

MARITIME SAFETY AGENCY

TOKARA medium patrol vessels (2003-2013)

Tokara 2010

Name No Yard No Builder Laid down Launched Comp Fate
とから [Tokara] PM21   Japan Marine Universal, Keihin 22.2.2002 4.12.2002 12.3.2003 in service (2019)
ふくえ [Fukue] PM22   Mitsubishi, Shimonoseki 12.3.2002 10.12.2002 12.3.2003 in service (2019)
おいらせ [Oirase] PM23   Japan Marine Universal, Keihin 27.3.2003 9.12.2003 18.3.2004 in service (2019)
ふじ [Fuji] PM24   Japan Marine Universal, Keihin 12.3.2007 10.1.2008 30.4.2008 in service (2019)
えちぜん [Echizen] PM25   Japan Marine Universal, Keihin 12.3.2007 27.11.2007 30.4.2008 in service (2019)
きくち [Kikuchi] PM26   Japan Marine Universal, Keihin 12.3.2007 25.4.2008 17.2.2009 in service (2019)
よしの [Yoshino] PM27   Japan Marine Universal, Keihin 12.3.2007 8.7.2008 26.3.2009 in service (2019)
いすず [Isuzu] PM28   Japan Marine Universal, Keihin 9.11.2007 10.10.2008 26.3.2009 in service (2019)
やまくに [Yamakuni] PM29   Japan Marine Universal, Keihin 9.11.2007 2.12.2008 29.6.2009 in service (2019)
かの [Kano] PM30   Japan Marine Universal, Keihin 25.6.2008 16.4.2009 16.12.2009 in service (2019)
あぶくま [Abakuma] PM31   Japan Marine Universal, Keihin 25.6.2008 22.7.2009 8.3.2010 in service (2019)
みなべ [Minabe] PM32   Japan Marine Universal, Keihin 25.6.2008 16.10.2009 8.3.2010 in service (2019)
まつうら [Matsuura] PM33   Japan Marine Universal, Keihin 18.3.2009 9.4.2010 14.9.2010 in service (2019)
ちくご [Chikugo] PM34   Japan Marine Universal, Keihin 18.3.2009 2.6.2010 1.12.2010 in service (2019)
くろせ [Kurose], 8.2013- みやこ [Miyako], 12.2018- はりみず [Harimizu] PM35   Japan Marine Universal, Keihin 20.10.2009 10.9.2010 5.4.2011 in service (2019)
おきつ [Okitsu] PM36   Japan Marine Universal, Keihin 2.12.2009 7.1.2011 28.6.2011 in service (2019)
くなしり [Kunashiri] PM37   Japan Marine Universal, Keihin 22.4.2010 7.4.2011 20.2.2012 in service (2019)
おおみ [Oomi] PM38   Japan Marine Universal, Keihin 22.4.2010 26.7.2011 31.5.2012 in service (2019)
おくしり [Okushiri] PM39   Japan Marine Universal, Keihin 29.9.2010 26.6.2012 29.3.2013 in service (2019)
なつい [Matsui], 1.2019- まべち [Mabechi] PM40   Japan Marine Universal, Keihin 29.9.2010 2012 27.6.2013 in service (2019)



Displacement standard, t

335

Displacement normal, t

350

Length, m

56.0

Breadth, m

8.50

Draught, m

3.00

No of shafts

3 waterjets

Machinery

3 diesels

Power, h. p.

15000

Max speed, kts

30

Fuel, t

diesel oil

Endurance, nm(kts)



Armament

1 x 3 - 20/76 JM-61-MB Sea Vulcan, 1 x 1 - 12.7/90

Electronic equipment

radar

Complement

20

Project history: Only the two outboard waterjets have "bucket"-type rudders. PM41 and PM42 were cancelled.

Modernizations: None.

Naval service: No significant events.

Fuji 2008
