Names |
CL01 いそかぜ [Isokaze] CL02 はやかぜ [Hayakaze] CL03 なだかぜ [Nadakaze] CL04 ことかぜ [Kotokaze] |
|
Builders |
Yokohama Yacht: CL01-04 |
|
Commissioned |
1989: CL01, 02 1991: CL03, 04 |
|
Losses |
none |
|
Transfers |
none |
|
Discarding |
2016: CL01, 02 2017: CL03, 04 |
|
Displacement standard, t |
19 |
|
Displacement full, t |
21 |
|
Length, m |
17.0 |
|
Breadth, m |
4.30 |
|
Draught, m |
1.00 |
|
No of shafts |
2 |
|
Machinery |
01, 02: 2 Nissan RD10-TA06 diesels 03, 04: 2 Mitsubishi 256Y-MTK diesels |
|
Power, h. p. |
01, 02: 900 03, 04: 1400 |
|
Max speed, kts |
01, 02: 20 03, 04: 29 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
01, 02: 180(19) 03, 04: 150(29) |
|
Armament |
none |
|
Electronic equipment |
radar |
|
Complement |
01, 02: 5 03, 04: 6 |
Project history: Revised Yamayuri design, with higher superstructure and finer hull lines. Second pair is considered a separate class, with greater displacement and more powerful engines.
Modernizations: None.
Naval service: No significant events.
Isokaze 2003
