Hida 2010
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| ひだ [Hida] | PL51 | Mitsubishi, Shimonoseki | 21.1.2005 | 9.8.2005 | 18.4.2006 | in service (2019) | |
| あかいし [Akaishi] | PL52 | Mitsubishi, Shimonoseki | 21.1.2005 | 21.10.2005 | 18.4.2006 | in service (2019) | |
| きそ [Kiso] | PL53 | IHI, Yokohama | 15.3.2006 | 17.8.2007 | 11.3.2008 | in service (2019) |
|
Displacement standard, t |
1800 |
|
Displacement normal, t |
2000 |
|
Length, m |
95.0 |
|
Breadth, m |
12.6 |
|
Draught, m |
4.00 hull 6.00 max |
|
No of shafts |
4 waterjets |
|
Machinery |
4 MTU 20V1163 TB93 diesels |
|
Power, h. p. |
|
|
Max speed, kts |
30 |
|
Fuel, t |
diesel oil |
| Endurance, nm(kts) | |
|
Armament |
1 x 1 - 40/60 Mk 3, 1 x 3 - 20/76 JM-61-MB Sea Vulcan, helicopter deck |
| Electronic equipment | 2x JMA radars, e/o director |
|
Complement |
Project history: Long, flush deck aft serves as a helicopter platform, though the class does not have a hangar.
Modernizations: None.
Naval service: No significant events.
Akaishi 2007
