Perla 1940
Iride 1940
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Ambra | OTO, Muggiano | 8.1935 | 28.5.1936 | 8.1936 | scuttled 9.9.1943 | ||
| Berillo | CRDA, Monfalcone | 9.1935 | 14.6.1936 | 8.1936 | sunk 2.10.1940 | ||
| Corallo | CRDA, Monfalcone | 9.1935 | 2.8.1936 | 9.1936 | sunk 13.12.1942 | ||
| Diaspro | CRDA, Monfalcone | 9.1935 | 5.7.1936 | 8.1936 | discarded 2.1948 | ||
| Gemma | CRDA, Monfalcone | 9.1935 | 21.5.1936 | 7.1936 | sunk 8.10.1940 | ||
| Iride | OTO, Muggiano | 9.1935 | 30.7.1936 | 11.1936 | to Nationalist Spain 10.1937-1/1938 (González López), sunk 22.8.1940 | ||
| Malacite | OTO, Muggiano | 8.1935 | 15.7.1936 | 11.1936 | sunk 9.2.1943 | ||
| Onice | OTO, Muggiano | 8.1935 | 15.6.1936 | 9.1936 | to Nationalist Spain 10.1937-1/1938 (Aguilar Tablada), discarded 3.1947 | ||
| Perla | CRDA, Monfalcone | 8.1935 | 3.5.1936 | 7.1936 | captured by Britain 9.7.1942 (Greek Ματρώζος [Matrozos]) | ||
| Turchese | CRDA, Monfalcone | 9.1935 | 19.7.1936 | 9.1936 | discarded 2.1948 |
|
Displacement standard, t |
622 - 626 |
|
Displacement normal, t |
680 / 844 |
|
Length, m |
60.2 |
|
Breadth, m |
6.45 |
|
Draught, m |
4.70 |
|
No of shafts |
2 |
|
Machinery |
Ambra, Malachite: 2 Tosi diesels / 2 Marelli electric motors Berillo, Gemma, Iride, Onice, Perla: 2 Fiat diesels / 2 CRDA electric motors Corallo, Diaspro, Turchese: 2 CRDA diesels / 2 CRDA electric motors |
|
Power, h. p. |
1200 / 800 |
|
Max speed, kts |
14 / 7.5 |
|
Fuel, t |
diesel oil 80 |
| Endurance, nm(kts) | 2500(12) / 74(4) |
|
Armament |
1 x 1 - 100/47 OTO 1935, 2 x 1 - 13.2/76 or 2 x 2 - 13.2/76, 6 - 533 TT (4 bow, 2 stern, 12) |
| Electronic equipment | hydrophone |
|
Complement |
45 |
| Diving depth operational, m | 80 |
Project history: Repetition of Sirena class with a little increased fuel stowage.
Iride and Ambra were converted for carrying of human torpedoes in 1940 and 1942 respectively. 100mm/47 gun has been thus removed, and on deck four (Iride) or three (Ambra) cylindrical transportation containers were installed.
Modernizations: 1940, Iride: - 1 x 1 - 100/47; + 4 SLC human torpedoes.
1942, Ambra: - 1 x 1 - 100/47; + 3 SLC human torpedoes
Naval service: Iride 22.8.1940 was sunk by torpedo from air group of British aircraft carrier Eagle near Tobruk. Berillo was sunk 2.10.1940 in Mediterranean sea by DCs of British destroyers Hasty and Havock. Gemma was erroneously sunk 8.10.1940 in Aegean sea by Italian submarine Tricheco. Perla was captured 9.7.1942 near Beirut by British corvette Hyacinth, transferred to Greece and renamed Matrozos. Corallo was sunk 13.12.1942 near Bougie (Algeria) by gunfire of British sloop Enchantress. Malacite was sunk 9.2.1943 S of Sardinia by Dutch submarine Dolfijn. Ambra was scuttled by crew 9.9.1943 in La Spezia harbour.
Turchese
