Argo 1940
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Argo | CRDA, Monfalcone | 10.1931 | 27.11.1936 | 8.1937 | scuttled 11.9.1943 | ||
| Velella | CRDA, Monfalcone | 10.1931 | 12.12.1936 | 9.1937 | sunk 7.9.1943 |
|
Displacement standard, t |
689 |
|
Displacement normal, t |
780 / 1000 |
|
Length, m |
63.2 |
|
Breadth, m |
6.93 |
|
Draught, m |
4.46 |
|
No of shafts |
2 |
|
Machinery |
2 Fiat diesels / 2 CRDA electric motors |
|
Power, h. p. |
1500 / 800 |
|
Max speed, kts |
14 / 8 |
|
Fuel, t |
diesel oil 60 (norm.) |
| Endurance, nm(kts) | 5300(14) / 100(3) |
|
Armament |
1 x 1 - 100/47 OTO 1931, 2 x 2 - 13.2/76, 6 - 533 TT (4 bow, 2 stern, 10) |
| Electronic equipment | hydrophone |
|
Complement |
46 |
| Diving depth operational, m | 90 |
Project history: Ordered by Portugal in 1931, but soon the contract has been terminated, and in 1935 it is redeemed by Italian Government for own Navy. The design was developed by builder as moderated variant of Balilla class. Partially double-hulled.
Successful medium submarines with high endurance and easy manoeuvrability. Rather low speed became an appreciable lack. They served as prototype for wartime built submarines of Flutto class.
Modernizations: None.
Naval service: Velella was sunk 7.9.1943 in a bay of Salerno by British submarine Shakespeare. Argo was scuttled 11.9.1943 at Monfalcone DYd.
Argo
