Stefano Türr 1937
|
Names |
Stefano Türr |
|
Builders |
CMA, Marina di Pisa: Stefano Türr |
|
Completed |
1937: Stefano Türr |
|
Losses |
none |
|
Transfers |
none |
|
Discarding |
7/1941: Stefano Türr |
|
Displacement standard, t |
59 |
|
Displacement full, t |
64 |
|
Length, m |
30.7 pp 32.0 oa |
|
Breadth, m |
5.95 |
|
Draught, m |
0.86 |
|
No of shafts |
4 |
|
Machinery |
4 Fiat diesels |
|
Power, h. p. |
3000 |
|
Max speed, kts |
30 |
|
Fuel, t |
diesel oil |
| Endurance, nm(kts) | 750(25) |
|
Armament |
3 x 1 - 13.2/76, 1 x 1 - 6.5/115, 4 - 450 TT, 12 DC |
| Electronic equipment | presumably hydrophone |
|
Complement |
16 |
Project history: Experimental MTB with increased, in comparison with all previous Italian boats, displacement. Design was developed by Baglietto. In a hull structure aluminium alloys were widely used for the weight decrease. Boat was appeared unsuccessful, never reached designed 34kts.
Modernizations: None.
Naval service: No significant events.
Stefano Türr during trials
