lead-boat No 800 1980
|
Names |
830-839 3 more units |
|
Builders |
Israeli Aircraft Industries, Be'er Sheva: 830-839 and 3 more |
|
Commissioned |
2004: 830 2005: 831, 832 2006: 833-835 2007-2009: 836-839 2016: 3 units |
|
Losses |
none |
|
Transfers |
none |
|
Discarding |
in service (2019): 830-839 and 3 more |
|
Displacement standard, t |
64 |
|
Displacement full, t |
72 |
|
Length, m |
27.4 |
|
Breadth, m |
5.74 |
|
Draught, m |
1.20 |
|
No of shafts |
2 waterjets |
|
Machinery |
2 MTU 12V4000 M90 diesels |
|
Power, h. p. |
5400 |
|
Max speed, kts |
49 |
|
Fuel, t |
diesel oil |
| Endurance, nm(kts) | |
|
Armament |
1 x 1 - 25/75 Typhoon, 1 x 1 - 20/70 Mk 10, 2 x 1 - 7.6/90 |
| Electronic equipment | Sperry Bridgemaster radar, MSIS e/o system |
| Complement |
12 |
Project history: Super Dvora Mk 3, lengthened Mk 2 with modern armament. Aluminium construction. Can be armed with depth charges, ASW torpedoes or 130mm barrage rocket launchers.
Modernizations: None.
Naval service: No significant events.
2006
© Ivan Gogin, 2019
