INDONESIAN NAVY (INDONESIA)

NON-NAVAL FORCES

RANTOS patrol craft (2015-16)

Name No Yard No Builder Laid down Launched Comm Fate
Rantos P210   PT Karimun Anugrah Segati   10.2015 17.10.2015 in service (2019)
Grantin P211   PT Karimun Anugrah Segati   10.2015 2015 in service (2019)
Pasatimpo P212   PT Karimun Anugrah Segati   10.2015 2015 in service (2019)
Salawaku P213   PT Karimun Anugrah Segati 20.10.2014 13.12.2015 8.3.2016 in service (2019)
Damaru P214   PT Karimun Anugrah Segati     2016 in service (2019)
Jembio P215   PT Karimun Anugrah Segati     2016 in service (2019)
Ular Laut 4805   PT Palindo Marine, Tanjung Ucang     2015 in service (2019)
Belut Laut 4806         2015 in service (2019)



Displacement standard, t



Displacement full, t

478

Length, m

39.5 pp 42.8 oa

Breadth, m

7.80

Draught, m



No of shafts

2

Machinery

2 MAN diesels

Power, h. p.



Max speed, kts

24

Fuel, t

diesel oil

Endurance, nm(kts)

Armament



Electronic equipment

radar
Complement 35

Project history: Patrol craft. Steel hull, aluminium superstructure.

Modernizations: None.

Naval service: No significant events.

Rantos
