T43
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| T37 | Schichau, Elbing | 1943 | 29.4.1944 | --- | scuttled incomplete 26.7.1946 | ||
| T38 | Schichau, Elbing | 1943 | 17.6.1944 | --- | scuttled incomplete 26.7.1946 | ||
| T39 | Schichau, Elbing | 1943 | 22.7.1944 | --- | scuttled incomplete 26.7.1946 | ||
| T40 | Schichau, Elbing | 1943 | 2.9.1944 | --- | scuttled incomplete 23.3.1945 | ||
| T41 | Schichau, Elbing | 1943 | 12.9.1944 | --- | scuttled incomplete 1945 | ||
| T42 | Schichau, Elbing | 1943 | 10.10.1944 | --- | scuttled incomplete 1945 | ||
| T43 | Schichau, Elbing | 1943 | --- | --- | BU incomplete 3.1945 | ||
| T44 | Schichau, Elbing | 1944 | --- | --- | BU incomplete 3.1945 | ||
| T45 | Schichau, Elbing | 1944 | --- | --- | BU incomplete 3.1945 | ||
| T46 | Schichau, Elbing | 1944 | --- | --- | BU incomplete 3.1945 | ||
| T47 | Schichau, Elbing | 1944 | --- | --- | BU incomplete 3.1945 | ||
| T48 | Schichau, Elbing | 1944 | --- | --- | BU incomplete 3.1945 | ||
| T49 | Schichau, Elbing | 1944 | --- | --- | BU incomplete 3.1945 | ||
| T50 | Schichau, Elbing | 1944 | --- | --- | BU incomplete 3.1945 |
|
Displacement standard, t |
1493 |
|
Displacement full, t |
2155 |
|
Length, m |
102.0 wl 106.0 oa |
|
Breadth, m |
10.7 |
|
Draught, m |
2.94 |
|
No of shafts |
2 |
|
Machinery |
2 sets Wagner geared steam turbines, 4 Wagner boilers |
|
Power, h. p. |
40000 |
|
Max speed, kts |
34 |
|
Fuel, t |
oil 582 |
| Endurance, nm(kts) | 6500(19) |
|
Armament |
4 x 1 - 105/42 SK C/32, 2 x 2 - 37/69 FlaK M/42, 1 x 4 - 20/65 C/38, 2 x 2 - 20/65 C/38, 2 x 3 - 533 TT, 4 DCT, 6 DCR (32), 50 mines |
| Electronic equipment | FuMO 33, FuMO 63, FuMO 231 radars, S-Gerät sonar, GHG hydrophone, FuMB 3 Bali, FuMB 4 Sumatra ECM suites |
|
Complement |
206 |
Project history: Improved and enlarged variant of type 1939, would had optical/electronic rangefinders developed previously for 1944 type destroyer, but with old artillery types. T40 - 50 were destroyed by builders when Red Army approached Elbing, almost completed T37 - 39 were transferred to USA and scuttled.
