T61
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| T61 | 691 | Wilton Fijenoord, Schiedam, Netherlands | 1942 | 6.1944 | --- | sunk incomplete 12.9.1944 | |
| T62 | 692 | Wilton Fijenoord, Schiedam, Netherlands | 1942 | --- | --- | BU incomplete 1946 | |
| T63 | 243 | Rotterdam Droogdook Mij, Netherlands | 1942 | 28.10.1944 | --- | scuttled incomplete 31.12.1946 | |
| T64 | 244 | Rotterdam Droogdook Mij, Netherlands | 1942 | --- | --- | BU incomplete 1946 | |
| T65 | 224 | De Schelde, Vlissingen, Netherlands | 1942 | 8.7.1944 | --- | BU incomplete 5.1946 | |
| T66 | 225 | De Schelde, Vlissingen, Netherlands | 1942 | --- | --- | destroyed incomplete 1944 | |
| T67 | 305 | Wilton Fijenoord, Schiedam, Netherlands | 1942 | --- | --- | BU incomplete 1946 | |
| T68 | 306 | Wilton Fijenoord, Schiedam, Netherlands | 1942 | --- | --- | BU incomplete 1946 | |
| T69 | 693 | Rotterdam Droogdook Mij, Netherlands | 1942 | --- | --- | BU incomplete 1946 | |
| T70 | 245 | Rotterdam Droogdook Mij, Netherlands | 1942 | --- | --- | BU incomplete 1946 | |
| T71 | 226 | De Schelde, Vlissingen, Netherlands | 1942 | --- | --- | BU incomplete 1946 | |
| T72 | 309 | De Schelde, Vlissingen, Netherlands | 1942 | --- | --- | BU incomplete 1946 |
|
Displacement standard, t |
1931 |
|
Displacement full, t |
2566 |
|
Length, m |
110.0 wl 114.5 oa |
|
Breadth, m |
11.3 |
|
Draught, m |
3.24 normal 3.81 max |
|
No of shafts |
2 |
|
Machinery |
2 sets Parsons geared steam turbines, 3 Yarrow boilers |
|
Power, h. p. |
45000 |
|
Max speed, kts |
34.8 |
|
Fuel, t |
oil 561 |
| Endurance, nm(kts) | 2100(19) |
|
Armament |
4 x 1 - 128/42 SK C/34, 2 x 2 - 37/69 FlaK M/42, 2 x 4 - 20/65 C/38, 2 x 4 - 533 TT, 4 DCT, 6 DCR (32), 50 mines |
| Electronic equipment | 2x FuMO 63 radars, S-Gerät sonar, GHG hydrophone, FuMB 3 Bali, FuMB 4 Sumatra ECM suites |
|
Complement |
223 |
Project history: These ships were designed around machinery already available on Dutch shipyards for incomplete destroyers. As result there were in fact genuine destroyers, which were to built in Dutch yards. T61 was torpedoed by Allied aircraft being towed to Germany for fitting out. T66 was bombed on slip in 1944. Remaining turbines and boilers were later used for Dutch postwar destroyers of Holland class.
