U2111 1944
|
Names |
U2111 - 2200, U2251 - 2300 |
|
Builders |
Germaniawerft, Kiel: U2111 - 2113 CRDA, Monfalcone with assisting of Simmering,Graz and Pauker, Wien: U2251 - 2300 |
|
Commissioned |
5-8/1944: U2111 - 2113, 2251 - 2300 |
|
Losses |
U2114 - 2200 (incomplete), losses are unknown |
|
Transfers |
none |
|
Discarding |
unknown |
|
Displacement standard, t |
|
|
Displacement normal, t |
11.8 - 12.5 / 17.2 |
|
Length, m |
10.5 |
|
Breadth, m |
1.30 |
|
Draught, m |
1.40 |
|
No of shafts |
1 |
|
Machinery |
1 AEG electric motor |
|
Power, h. p. |
12 |
|
Max speed, kts |
5.6 / 6 |
|
Fuel, t |
none |
| Endurance, nm(kts) | 45-78(3) |
|
Armament |
50 units: 1 - 533 TT (bottom-drop collar) 3 units: 1 mine |
|
Complement |
2 |
| Diving depth operational, m | 30 |
Project history: Design was developed in early 1944 on the basis of captured Britsh midget submarine. Intended for actions against stationary targets (ships on anchorages and in harbours) and were originally armed with dropped explosive charge supposed to be dumped under enemy ship. Very soon armament was replaced by a torpedo, but three boats carried magnetic mines instead of torpedoes. In the absence of a surface machinery and a gyro-compass they differed by small action radius and thereof did not participate in operations.
Modernizations: None.
Naval service: No significant events.
© Ivan Gogin, 2008-14
