Foucault 1915
Curie 1914
Curie 1919
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Brumaire | Q060 | Q26 | Arsenal de Cherbourg | 1906 | 29.4.1911 | 1913 | stricken 1930 |
| Frimaire | Q062 | Q27 | Arsenal de Cherbourg | 1906 | 26.8.1911 | 1913 | stricken 1923 |
| Nivôse | Q063 | Q28 | Arsenal de Cherbourg | 1906 | 6.1.1912 | 1913 | stricken 1921 |
| Foucault | Q070 | Q31 | Arsenal de Cherbourg | 1907 | 15.6.1912 | 1914 | sunk 15.9.1915 |
| Euler | Q071 | Q32 | Arsenal de Cherbourg | 1907 | 12.10.1912 | 1914 | stricken 1923 |
| Franklin | Q072 | Q33 | Arsenal de Cherbourg | 1907 | 22.3.1913 | 1914 | stricken 1922 |
| Faraday | Q078 | Arsenal de Rochefort | 1906 | 27.6.1911 | 1913 | stricken 1921 | |
| Volta | Q079 | Arsenal de Rochefort | 1906 | 23.9.1911 | 1913 | stricken 10.1922 | |
| Newton | Q080 | Arsenal de Rochefort | 1907 | 20.5.1912 | 1914 | stricken 12.1925 | |
| Montgolfier | Q081 | Arsenal de Rochefort | 1907 | 18.4.1912 | 1914 | stricken 1921 | |
| Bernoulli | Q083 | Arsenal de Toulon | 1906 | 1.6.1911 | 1913 | sunk 13.2.1918 | |
| Joule | Q084 | Arsenal de Toulon | 1906 | 7.9.1911 | 1913 | sunk 1.5.1915 | |
| Coulomb | Q085 | Arsenal de Toulon | 1907 | 13.6.1912 | 1914 | stricken 1919 | |
| Arago | Q086 | Arsenal de Toulon | 1907 | 29.6.1912 | 1914 | stricken 1921 | |
| Curie | Q087 | Arsenal de Toulon | 1907 | 18.7.1912 | 1914 | captured by Austria-Hungary 20.12.1914 (U14), returned 7.1919, stricken 3.1928 | |
| Le Verrier | Q088 | Arsenal de Toulon | 1907 | 31.10.1912 | 1914 | stricken 1925 |
| Data variant | as completed |
|
Displacement standard, t |
|
|
Displacement normal, t |
397 / 551 |
|
Length, m |
52.1 |
|
Breadth, m |
5.14 |
|
Draught, m |
3.10 |
|
No of shafts |
2 |
|
Machinery |
2 MAN-type diesels / 2 electric motors |
|
Power, h. p. |
840 / 660 |
|
Max speed, kts |
13 / 8.8 |
|
Fuel, t |
diesel oil |
| Endurance, nm(kts) | 1700(10) / 84(5) |
|
Armament |
7 - 450 TT (1 bow, 4 Drzewiecki drop-collars, 2 ext abeam CT, 8) |
| Complement | 29 |
| Diving depth operational, m | 40 |
Project history: Provided under the 1906 programme. Double-hull submersibles designed by Laubeuf - they were a diesel-powered version of Pluviôse class. MAN type diesels produced by A C Loire, Sautter-Harlé, Normand, Indret and Sabathé.
It was planned in 1917 to convert six boats of the Brumaire class into minelaying submarines but the project was abandoned.
Modernizations: 1916, Arago, Faraday, Le Verrier and others: + 1 x 1 - 47/50 M1902 or 1 x 1 - 75/35 M1897
7/1919, Curie was returned as given in the table
| Data variant | Curie as returned after Austria-Hungarian Navy |
|
Displacement standard, t |
|
|
Displacement normal, t |
425 / 554 |
|
Length, m |
52.1 |
|
Breadth, m |
5.14 |
|
Draught, m |
3.10 |
|
No of shafts |
2 |
|
Machinery |
2 Grazer diesels / 2 electric motors |
|
Power, h. p. |
900 / 560 |
|
Max speed, kts |
13.5 / 7 |
|
Fuel, t |
diesel oil |
| Endurance, nm(kts) | 2300(10) / 150(2) |
|
Armament |
1 x 1 - 88/27 Ubts L/30, 7 - 450 TT (1 bow, 2 Drzewiecki drop-collars, 2 ext abeam CT, 2 ext aft, 8) |
| Complement | 29 |
| Diving depth operational, m | 40 |
Naval service: Bernouilli was lost on Austrian mine 13.2.1918. Foucault was sunk by Austro-Hungarian aircraft off Cattaro 15.9.1915. Joule was mined in the Dardanelless 1.5.1915 on Turkish mine. Curie 20.12.1914 at attempt to get into harbour of Pola entangled in anti-submarine nets and was scuttled by crew. Later Austrians salvaged her and commissioned as U14; after war submarine was returned to France and received former name.
Curie after war
Many thanks to Wolfgang Stöhr for additional information on this page.
