Names |
PM32 Armoise |
|
Builders |
DCN, Lorient: PM32 |
|
Completed |
1995: PM32 |
|
Losses |
none |
|
Transfers |
none |
|
Discarding |
in service (2019): PM32 |
|
Displacement standard, t |
73 |
|
Displacement full, t |
93 |
|
Length, m |
30.5 wl 32.2 oa |
|
Breadth, m |
6.10 |
|
Draught, m |
1.80 |
|
No of shafts |
2 + 1 water-jet |
|
Machinery |
2 MWM-Deutz TBD234V15 diesels + 1 MWM-Deutz TBD234V16 diesel |
|
Power, h. p. |
2120 + 425 = 2545 |
|
Max speed, kts |
23 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
1200(16) |
|
Armament |
1 x 1 - 7.5/90 |
|
Electronic equipment |
Racal-Decca C180/6, Raytheon R20XX radars |
|
Complement |
9 |
Project history: Medium patrol boat. Maritime Police.
Modernizations: None.
Naval service: No significant events.
Armoise 2013
