Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
90 | Swiftships, Morgan City, USA | 2006 | in service (2019) | ||||
91 | Swiftships, Morgan City, USA | 2006 | in service (2019) | ||||
92 | Swiftships, Morgan City, USA | 2006 | in service (2019) | ||||
93 | Swiftships, Morgan City, USA | 2007 | in service (2019) | ||||
94 | Swiftships, Morgan City, USA | 2007 | in service (2019) | ||||
95 | Swiftships, Morgan City, USA | 2007 | in service (2019) |
Displacement standard, t |
|
Displacement full, t |
116 |
Length, m |
26.1 |
Breadth, m |
6.10 |
Draught, m |
1.50 |
No of shafts |
2 waterjets |
Machinery |
2 Caterpillar 3512B diesels |
Power, h. p. |
|
Max speed, kts |
40 |
Fuel, t |
diesel oil |
Endurance, nm(kts) |
|
Armament |
2 x 1 - 20/90 GAM-B01, 2 x 1 - 12.7/90 |
Sensors |
radar |
Complement |
12 |
Project history: Swiftships Protector design.
Modernizations: None.
Naval service: No significant events.
90 2006
© Ivan Gogin, 2018-19
