similar L9070 1990
| Name | No | Yard No | Builder | Laid down | Launched | Comp. | Fate |
| (ex-Dague, ex-L9052) | SFCN, Villeneuve-la-Garenne, France | 10.9.1987 | 19.12.1987 // 30.6.2012 | in service (2020) |
|
Displacement standard, t |
325 |
|
Displacement full, t |
726 |
|
Length, m |
55.9 pp 59.4 oa |
|
Breadth, m |
11.9 |
|
Draught, m |
1.40 hull 1.70 max |
|
No of shafts |
2 |
|
Machinery |
2 SACM UD30V12 MB diesels |
|
Power, h. p. |
1400 |
|
Max speed, kts |
12 |
|
Fuel, t |
diesel oil 20 |
| Endurance, nm(kts) | 1000(10) |
|
Armament |
2 x 1 - 12.7/90 |
| Electronic equipment | Decca, Furuno radars |
| Capacity |
210 t of cargo, 180 troops |
|
Complement |
17 |
Project history: Former French LCU of EDIC700 class.
Modernizations: None.
Naval service: No significant events.
2013
