| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Dagmar | Orlogsværftet, København | 1860 | 1.11.1861 | 1862 | stricken 7.1901 |
|
Displacement normal, t |
1175 |
|
Displacement full, t |
1222 |
|
Length, m |
54.4 |
|
Breadth, m |
10.3 |
|
Draught, m |
5.0 |
|
No of shafts |
1 |
|
Machinery |
1 HDA |
|
Power, h. p. |
500 |
|
Max speed, kts |
9 |
|
Fuel, t |
coal |
| Endurance, nm(kts) | |
|
Armament |
16 x 1 - 167/15.9 30pdr 60ctr 2.946 Ton Armstrong SB |
|
Complement |
190 |
Project history: Wooden screw sloop, rated in Dutch Navy as corvette.
Modernizations: 1864: - 2 x 1 - 167/15.9; + 2 x 1 - 143/ 18pdr 40ctr 1.964 Ton MLR
~1866: - 14 x 1 - 167/15.9, 2 x 1 - 143/ ; + 8 x 1 - 153/19 24pdr 62ctr 3.044 Ton Akers M1864 BLR
1885: new armament consisted of 8 x 1 - 120/27 RK L/30 C/84, 2 x 5 - 37/17 M.1875
Naval service: No significant events.
Many Thanks to Kent Crawford for unique correction of information about ship's guns on this page.
