PEOPLE`S LIBERATION ARMY NAVY (PEOPLE`S REPUBLIC OF CHINA)
CHANGCHENG 338 submarines (project 039B, 2012-2015)
Changcheng 330 2010
| Name | No | Builder | Laid down | Launched | Comp | Fate |
| Type 039A | ||||||
| 长城 330 [Changcheng 330] | 330 | Wuchang, Wuhan | 31.5.2004 | 4/2005 | in service (2019) | |
| 长城 331 [Changcheng 331] | 331 | Wuchang, Wuhan | 31.8.2007 | 2009 | in service (2019) | |
| 长城 332 [Changcheng 332] | 332 | Wuchang, Wuhan | 11/2007 | 2009 | in service (2019) | |
| 长城 333 [Changcheng 333] | 333 | Wuchang, Wuhan | 4/2008 | 2010 | in service (2019) | |
| Type 039B | ||||||
| 长城 334 [Changcheng 334] | 334 | Wuchang, Wuhan | 10.10.2008 | 2011 | in service (2019) | |
| 长城 335 [Changcheng 335] | 335 | Wuchang, Wuhan | 3.10.2010 | 2011 | in service (2019) | |
| 长城 336 [Changcheng 336] | 336 | Wuchang, Wuhan | 11/2010 | 2012 | in service (2019) | |
| 长城 337 [Changcheng 337] | 337 | Wuchang, Wuhan | 16.12.2010 | 2012 | in service (2019) | |
| 长城 338 [Changcheng 338] | 338 | Jiangnan, Changxing | 7.6.2011 | 2012 | in service (2019) | |
| 长城 339 [Changcheng 339] | 339 | Wuchang, Wuhan | 29.7.2011 | 2012 | in service (2019) | |
| 长城 340 [Changcheng 340] | 340 | Wuchang, Wuhan | 28.8.2011 | 2012 | in service (2019) | |
| 长城 341 [Changcheng 341] | 341 | Jiangnan, Changxing | 26.11.2011 | 2012 | in service (2019) | |
| 长城 342 [Changcheng 342] | 342 | Wuchang, Wuhan | 10.12.2013 | 2015 | in service (2019) | |
| 长城 343 [Changcheng 343] | 343 | Wuchang, Wuhan | 25.4.2014 | 2016 | in service (2019) | |
| 长城 344 [Changcheng 344] | 344 | Wuchang, Wuhan | 12/2016 | 2017 | in service (2019) | |
| 长城 345 [Changcheng 345] | 345 | Jiangnan, Changxing | 2018 | 2019 | building (2019) | |
| 长城 346 [Changcheng 346] | 346 | Jiangnan, Changxing | 2018 | 2019 | building (2019) | |
| 长城 347 [Changcheng 347] | 347 | Wuchang, Wuhan | 2018 | 2019 | building (2019) | |
|
Displacement standard, t |
|
|
Displacement normal, t |
2725 / 3600 |
|
Length, m |
type 039A: 72.0 type 039B: 74.9 |
|
Breadth, m |
8.40 hull |
|
Draught, m |
5.50 |
|
No of shafts |
1 |
|
Machinery |
4 MTU 16V396 SE 83/84 diesel-generators / AIP, 1 electric motor |
|
Power, h. p. |
6092 / 220 |
|
Max speed, kts |
16 / 23 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
8000(16) / 800(4) |
|
Armament |
type 039A: 6 - 533 TT (bow, 18, inc. Yin Ji-82 SSM (4 C-602) or 24-36 mines) type 039B: 1 x 10 YJ-81 SSM (VLS, 10 C-801) (may be), 6 - 533 TT (bow, 18, inc. Yin Ji-82 SSM (4 C-602) or 24-36 mines) |
|
Electronic equipment |
type 039A: type 359 radar, H/SQG-4 sonar suite (TSM2233 Eledone, TSM-2255, SQB-2 sonars), Type 921-A (SRW209) ECM suite, CCS type 039B: type 359 radar, H/SQG-4 sonar suite (TSM2233 Eledone, TSM-2255, SQB-2 sonars), H/SQC-207 sonar, Type 921-A (SRW209) ECM suite, CCS |
|
Complement |
58 |
|
Diving depth operational, m |
300 |
Project history: Type 039G with air-independent power plant. Also submarines presumably can launch 3M54 Club SSMs and YJ-18 supersonic SSMs (currently in development). Type 039B differs from the type 039A by having flank sonar array and (may be) VLS. Building of 20 type 039C submarines is planned.
Modernizations: None.
Naval service: No significant events.
2008
