PEOPLE`S LIBERATION ARMY NAVY (PEOPLE`S REPUBLIC OF CHINA)
|
Names |
70 boats |
|
Builders |
Hudong, Shanghai: 70 boats |
|
Commissioned |
1972-1984: 70 boats |
|
Losses |
none |
|
Transfers |
none |
|
Discarding |
2000s: 24 boats 2010s: 46 boats |
|
Displacement standard, t |
|
|
Displacement full, t |
47 |
|
Length, m |
20.9 |
|
Breadth, m |
4.20 |
|
Draught, m |
1.30 |
|
No of shafts |
1 |
|
Machinery |
1 12V150C diesel |
|
Power, h. p. |
300 |
|
Max speed, kts |
11.5 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
150(11.5) |
|
Armament |
magnetic and acoustic minesweeping gear |
|
Electronic equipment |
none |
|
Complement |
0 or 3 |
Project history: Remotely controlled drones, manned only by ferrying. Had electric propulsion for sweeping at 1-5kts.
Modernizations: None.
Naval service: No significant events.
1988
