PEOPLE`S LIBERATION ARMY NAVY (PEOPLE`S REPUBLIC OF CHINA)
1960
1980
|
Names |
82 boats |
|
Builders |
Kiangnan SY: 82 boats |
|
Completed |
1950 - 1955: 82 boats |
|
Losses |
none |
|
Transfers |
none |
|
Discarding |
1977: 10 boats 1978: 5 boats 1981: 7 boats early 1980s: 20 boats late 1990s: 40 boats |
|
Displacement standard, t |
42 |
|
Displacement full, t |
50 |
|
Length, m |
27.0 |
|
Breadth, m |
4.00 |
|
Draught, m |
1.50 |
|
No of shafts |
2 |
|
Machinery |
diesels |
|
Power, h. p. |
1000 |
|
Max speed, kts |
14 |
|
Fuel, t |
diesel oil |
| Endurance, nm(kts) | 400(9) |
|
Armament |
most: 2 x 2 - 25/82 type 61M some: 1 x 2 - 37/63 type 61, 1 x 2 - 12.7/92 |
| Electronic equipment | none |
|
Complement |
Project history: Small patrol boats. Low freeboard and inadequate propulsion.
Modernizations: None.
Naval service: No significant events.
1975
