LPM4400 patrol launches (2008-2014)

Names	LPM4400-4413 LPM4420-4431
Builders	Safe Boats International, Port Orchard, USA: LPM4400-4413, 4420-4431
Completed	2008-2014: LPM4400-4413, 4420-4431
Losses	none
Transfers	none
Discarding	in service (2019): LPM4400-4413, 4420-4431

Displacement standard, t

Displacement full, t

13

Length, m

12.8

Breadth, m

4.10

Draught, m
1.00

No of shafts

2 waterjets

Machinery

2 Caterpillar C9 diesels

Power, h. p.

550

Max speed, kts

36

Fuel, t

diesel oil

Endurance, nm(kts)
300(25)

Armament

2 x 1 - 7.6/90

Electronic equipment

Furuno radar

Complement

3

Project history: US 42ft Archangel design. Aluminium superstructure with polyethylene rigid foam collar.

Modernizations: None.

Naval service: No significant events.

2008

� Ivan Gogin, 2018-19

CHILEAN NAVY (CHILE)

COAST GUARD SHIPS

LPM4400 patrol launches (2008-2014)

Displacement standard, t
Displacement full, t	13
Length, m	12.8
Breadth, m	4.10
Draught, m	1.00
No of shafts	2 waterjets
Machinery	2 Caterpillar C9 diesels
Power, h. p.	550
Max speed, kts	36
Fuel, t	diesel oil
Endurance, nm(kts)	300(25)
Armament	2 x 1 - 7.6/90
Electronic equipment	Furuno radar
Complement	3
