Names |
LP01 Timbiras (ex-P8005) LP02 (ex-P8006) LP03 Mucuripe (ex-P8004) LP04 (ex-P8007) LP05 Rio (ex-P8002) LP07 Espadarte (ex-P8003) |
|
Builders |
Estaleiro do Sul, Porto Alegre: LP01-05, 07 |
|
Commissioned |
1991: LP01-04 1995: LP05, 07 |
|
Losses |
none |
|
Transfers |
none |
|
Discarding |
2010s: LP02, 04 in service (2019): LP01, 03, 05, 07 |
|
Displacement standard, t |
31 |
|
Displacement full, t |
37 |
|
Length, m |
17.5 pp 20.9 oa |
|
Breadth, m |
5.18 |
|
Draught, m |
1.45 |
|
No of shafts |
2 |
|
Machinery |
2 MTU 8V396 TB83 diesels |
|
Power, h. p. |
2000 |
|
Max speed, kts |
27 |
|
Fuel, t |
diesel oil 5 |
|
Endurance, nm(kts) |
600(15) |
|
Armament |
2 x 1 - 12.7/90 |
|
Electronic equipment |
Decca RM1070A radar |
|
Complement |
8 |
Project history: Tracker II type.
Modernizations: None.
Naval service: No significant events.
2000
